Panasonic CU-MC140KE - Replacement Parts List

– 46 –
MAC9702008C2
CS-MC90KE
Replacement Parts List
<Model: CS-MC90KE>
DESCRIPTION & NAME
CHASSY COMPLETE
FAN MOTOR
CROSS FLOW FAN COMPLETE
SCREW – CROSS FLOW FAN
BEARING ASS’Y
EVAPORATOR
TUBE ASS’Y COMPLETE
FLARE NUT (1/4")
FLARE NUT (3/8")
DISCHARGE GRILLE COMPLETE
MOTOR – AIR SWING
TAP – DRAIN TRAY
VANE
CONTROL BOARD
TERMINAL BOARD COMPLETE
POWER SUPPLY CORD
SLIDE SWITCH
TRANSFORMER COMPLETE
ELECTRONIC CONTROLLER
RECEIVER
INDICATOR COMPLETE
SENSOR COMPLETE
CONTROL BOARD TOP COVER
CONTROL BOARD FRONT COVER
CONTROL BOARD COVER PIECE
REMOTE CONTROL COMPLETE
REMOTE CONTROL CASE CO.
CONTROL PANEL
KNOB
KNOB
CONTACTOR
PCB – REMOTE CONTROL
INDICATOR
REMOTE CONTROL CASE
COVER
FRONT GRILLE COMPLETE
INTAKE GRILLE COMPLETE
PARTICULAR PIECE
AIR FILTER
SCREW – FRONT GRILLE
CAP – FRONT GRILLE
DRAIN HOSE
INSTALLATION PLATE
BAG COMPLETE – INSTALLATION SCREW
AIR PURIFYING FILTER COMPLETE
AIR PURIFYING FILTER
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
(Note) ● All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
● t marked parts are recommended to be kept in stock.
CS-MC90KE
CWD50C202
CWA92232
CWH02C053
CWH4580304
CWH64K007
CWB30C178
CWT01C237
CWH6002140
CWT25005
CWE20C480
CWA98245
CWH52C003
CWE24394
CWH10887
CWA28C471
CWA20C616
CWA04088
CWA40C246
CWA74813
CWA74321
CWE39C271
CWA50C521
CWH13383
CWH13C256
CWH13385
CWA75C560
CWE15C241
CWE311064
CWE17196A
CWE17286
CWA65036C
CWA74572
CWE39199
CWE15128A
CWB80040A
CWE11C590
CWE22C287
CWD93C070
CWD00215
XTN4+16C
CWH52230
CWH5880580
CWH36122
CWH82C194
CWD00C111
CWD00220
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
2
REMARKS
t
t
t
t
t
t
t
t
t
t
t
