– 52 –
MAC9702008C2
CS-MC90KE
Replacement Parts List
<Model: CU-3MC200KE>
DESCRIPTION & NAME
BASE FAN ASS'Y
COMPRESSOR
AIR GUIDER
SOUND PROOF COVER
FAN MOTOR BRACKET
CONDENSOR
FAN MOTOR
PROPELLER FAN
COMPRESSOR
3-WAY VALVE (LIQUID SIDE)
3-WAY VALVE (GAS SIDE)
COUPLING BRACKET
CAPILLARY TUBE
CAPILLARY TUBE
SOLENOID VALVE
COIL – SOLENOID VALVE
CONTROL BOARD
TRANSFORMER
ELECTRONIC CONTROLLER
CAPACITOR – COMPRESSOR
CAPACITOR – FAN MOTOR
ELECTRO MAGNETIC RELAY
TERMINAL BOARD
TERMINAL BOARD
OVERLOAD PROTECTOR
OVERLOAD PROTECTOR
TERMINAL COVER – COMPRESSOR
CABINET TOP PLATE
3-WAY VALVE (LIQUID SIDE)
CONTROL BOARD COVER
FRONT PANEL
CABINET SIDE PLATE
FAN GUARD
HANDLE
CAPILLARY TUBE
MOUNT RUBBER – COMPRESSOR
FUSE
FUSE HOLDER
SOUND – ARRESTER
HOLDER – OVERLOAD PROTECTOR
STRAINER
STRAINER
OPERATING INSTRUCTION
INSTALLATION INSTRUCTION
NUT COMPRESSOR
HOLDER CAPACITOR
NUT TERMINAL COVER
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
CU-3MC200KE
CWD50K572A
2PS193D2AA01
CWD31094A
CWH15071
CWD54179
CWB32C141
CWA95358
CWH00023
2PS134D2AA01
CWB01385
CWB01384
CWH35127A
CWB15315
CWB15199
CWB02117
CWA43C516
CWH10927
CWA40C192
CWA741165
CWA31655 (25µF, 440VAC)
CWA31289 (3.0µF, 450VAC)
–
CWA4711069
CWA28064
CWA12334
CWA12336
CWH7070204
CWE03032A
CWB01383
CWH13322
CWE06C111A
CWE04131A
CWD04183
CWE16037C
CWB15474
CWH50049
XBA2C31TR0
XCSCW00
CWG30267
CWH7041200
CWB11002
CWB11004
CWF561246
CWF61532
CWH56000
CWH30060
CWH7080300
QTY
1
1
1
1
1
1
1
1
1
2
3
1
2
1
2
1
1
1
1
2
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
6
2
2
2
2
1
1
1
1
6
2
2
REMARKS
t
t
t
t
t
t
t
t
t
t
t
t
t
t
(Note) ● All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
● t marked parts are recommended to be kept in stock.
