Panasonic CU-MC145KE - Replacement Parts List

21 Replacement Parts List
(Note)
•
“O” marked parts are recommended to be kept in stock.
<Model: CU-MC145KE>
NO. DESCRIPTION & NAME Q’TY CU-MC145KE REMARKS
1 BASE ASS’Y 1 CWD50K573A
2 SOUND PROOF COVER 1 CWH15066
3 FAN MOTOR BRACKET 1 CWD54168
4 CONDENSER 1 CWB32C142
5 FAN MOTOR 1 CWA95354 0
6 PROPELLER FAN 1 CWH00022
7 COMPRESSOR 1 2PS192D2AA02 0
8 3-WAY VALVE (LIQUID SIDE) 2 CWB01383 0
9 3-WAY VALVE (GAS SIDE) 2 CWB01384 0
10 COUPLING BRACKET (HOLDER - COUPLING) 1 CWH35075A
11 CAPILLARY TUBE 1 CWB15537
12 CAPILLARY TUBE 2 CWB15537
13 SOLENOID VALVE (2 WAY VALVE) 1 CWB02089
14 COIL - SOLENOID VALVE (V - C0IL COMP.) 1 CWA43C650 0
15 CONTROL BOARD 1 CWH10926
16 TRANSFORMER 1 CWA40C192 0
17 ELECTRONIC CONTROLLER 1 CWA741123 0
18 CAPACITOR - COMPRESSOR 1 CWA31656
(440VAC, 30µF)
0
19 CAPACITOR - FAN MOTOR 1 CWA31709
(430VAC, 1µF)
0
20 TERMINAL BOARD 1 CWA28064
21 OVERLOAD PROTECTOR 1 CWA12334 0
22 HOLDER - OVERLOAD PROTECTOR 1 CWH7041200
23 TERMINAL COVER - COMPRESSOR 1 CWH7070204
24 CABIBET TOP PLATE 1 CWE03061A
25 CABIBET BACK PLATE 1 CWE02071A
26 CONTROL BOARD COVER 1 CWH13236
27 FRONT PLATE 1 CWE06C109A
28 FAN GUARD 1 CWD04182
29 HANDLE 1 CWE16000E
30 SOUND - PROOF MATERIAL 1 CWG30267
31 MOUNT RUBBER - COMPRESSOR 3 CWH50049
32 STRAINER 1 CWB11002
33 OPERATING INSTRUCTION 1 CWF563178
34 INSTALLATION INSTRUCTION 1 CWF612104
35 NUT - COMPRESSOR 3 CWH56000 0
36 HOLDER CAPACITOR 1 CWH30071
37 NUT TERMINAL COVER 1 CWH7080300
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
