Panasonic CU-MC145KE - Replacement Parts List

25 Replacement Parts List
(Note)
•
“O” marked parts are recommended to be kept in stock.
<Model: CU-3MC205KE>
NO. DESCRIPTION & NAME Q’TY CU-3MC205KE REMARKS
1 BASE FAN ASS’Y 1 CWD50K663A
2 COMPRESSOR 1 2PS193D2AA01 0
3 AIR GUIDER 1 CWD31094A
4 SOUND PROOF COVER 1 CWH15071
5 FAN MOTOR BRACKET 1 CWD54179
6 CONDENSER 1 CWB32C141
7 FAN MOTOR 1 CWA95358
8 PROPELLER FAN 1 CWH00023
9 COMPRESSOR 1 2PS134D2AA01
10 3-WAY VALVE (LIQUID SIDE) 2 CWB01385 0
11 3-WAY VALVE (GAS SIDE) 3 CWB01384 0
12 COUPLING BRACKET 1 CWH35127A
13 CAPILLARY TUBE 2 CWB15315
14 CAPILLARY TUBE 1 CWB15199
15 SOLENOID VALVE 2 CWB02117
16 COIL - SOLENOID VALVE 1 CWA43C516 0
17 CONTROL BOARD 1 CWH10927 0
18 TRANSFORMER 1 CWA40C192 0
19 ELECTRONIC CONTROLLER 1 CWA741165 0
20 CAPACITOR - COMPRESSOR 2 CWA31656
(25µF, 440VAC)
0
21 CAPACITOR - FAN MOTOR 1 CWA31289
(3.0µF, 450VAC)
0
22 ELECTRO MAGNETIC RELAY 1 CWA00106 0
23 TERMINAL BOARD 1 CWA4711069
24 TERMINAL BOARD 1 CWA28064
25 OVERLOAD PROTECTOR 1 CWA12334 0
26 OVERLOAD PROTECTOR 1 CWA12336 0
27 TERMINAL COVER - COMPRESSOR 2 CWH7070204
28 CABINET TOP PLATE 1 CWE03032A
29 3-WAY VALVE (LIQUID SIDE) 1 CWB01383 0
30 CONTROL BOARD COVER 1 CWH13322
31 FRONT PANEL 1 CWE06C111A
32 CABINET SIDE PLATE 1 CWE04131A
33 FAN GUARD 1 CWD04183
34 HANDLE 1 CWE16037C
35 CAPILLARY TUBE 1 CWB15474
36 MOUNT RUBBER - COMPRESSOR 6 CWH50049
37 FUSE 2 XBA2C31TR0 0
38 FUSE HOLDER 2 XCSCW00
39 SOUND - ARRESTER 2 CWG30267
40 HOLDER - OVERLOAD PROTECTOR 2 CWH7041200
41 STRAINER 1 CWB11002
42 STRAINER 1 CWB11004
43 OPERATING INSTRUCTION 1 CWF563178
44 INSTALLATION INSTRUCTION 1 CWF612104
45 NUT COMPRESSOR 6 CWH56000
46 HOLDER CAPACITOR 2 CWH30060
47 NUT TERMINAL COVER 2 CWH7080300
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
