27 Replacement Parts List
(Note)
<Model: CU-MC245KE>
NO. DESCRIPTION & NAME Q’TY CU-MC245KE REMARKS
1 CHASSY ASS’Y (UPPER) 1 CWD50K625A
2 FAN MOTOR BRACKET 2 CWD54171
3 SCREW - FAN MOTOR BRACKET 8 CWH4580399
4 FAN MOTOR 2 CWA95319 0
5 SCREW - FAN MOTOR MOUNT 6 CWH55027
6 PROPELLER FAN 2 CWH00K040
7 NUT - PROPELLER FAN 2 CWH56032
8 COMPRESSOR 2 2KS224D5AA02 0
9 ANTI - VIBRATION BUSHING 6 CWH50055
10 NUT - COMPRESSOR MOUNT 6 CWH4582065
11 CONDENSER 2 CWB32C224
12 HOLDER COUPLING ASS’Y 2 CWH35K019A
13 3-WAY VALVE 2 CWB01379 0
14 2-WAY VALVE 2 CWB02243 0
15 TUBE ASS’Y (STRAINER CAPILLARY) 2 CWT01C239
16 SOUND PROOF BOARD 2 CWH15265
17 OVERLOAD PROTECTOR 2 CWA67C1211 0
18 TERMINAL COVER 2 CWH17038
19 HOLDER - O.L.P 2 CWH34033
20 NUT - TERMINAL COVER 2 CWH7080300
21 SOUND PROOF MATERIAL 2 CWG302078
22 CONTROL BOARD 2 CWH10878
23 TERMINAL BOARD ASS’Y 2 CWA28K217
24 CAPACITOR - COMPRESSOR 2 CWA31647 0
25 HOLDER CAPACITOR 2 CWH30057
26 CAPACITOR - FAN MOTOR 1,1 CWA31341, CWA31342 0
27 FUSE 2 XBA2C50TR0 0
28 CABINET ASS’Y 2 CWE00K318A 0
29 CABINET FRONT PLATE 1 CWE06C1026A
30 CONTROL BOARD COVER 2 CWH13C286
31 FUSE HOLDER 2 XCSCW011
32 OPERATING INSTRUCTION 1 CWF563178
33 INSTALLATION INSTRUCTION 1 CWF612121
34 CHASSY ASS’Y (LOWER) 1 CWD50K611A
35 CABINET FRONT PLATE 1 CWE06C1028A
36 FLAT PLATE 1 CWD64189A
37 FLAT PLATE 1 CWD911089A
38 FLAT PLATE 1 CWD90960A
39 FLAT PLATE 1 CWD90977A
40 FLAT PLATE 1 CWD90959A
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
The above parts are kept for seven years in accordance with MEI service policy. However, longer lead time will be taken in
supplying the non-numbered parts.
•
“O” marked parts are recommended to be kept in stock.
