23 Replacement Parts List
(Note)
<Model: CU-MC185KE>
NO. DESCRIPTION & NAME Q’TY CU-MC185KE REMARKS
1 BASE ASS’Y 1 CWD50K663A
2 AIR GUIDER FOR P.F. 1 CWD31094A
3 SOUND PROOF COVER 1 CWH15071
4 FAN MOTOR BRACKET 1 CWD54179
5 CONDENSER 1 CWB32C317
6 FAN MOTOR 1 CWA95269 0
7 PROPELLER FAN 1 CWH00023
8 COMPRESSOR 2 2PS134D2AA01 0
9 3-WAY VALVE (LIQUID SIDE) 2 CWB01383 0
10 3-WAY VALVE (GAS SIDE) 2 CWB01384 0
11 COUPLING BRACKET 1 CWH35083A
12 CAPILLARY TUBE 2 CWB15302
13 CONTROL BOARD 1 CWH10987
14 CAPACITOR - COMPRESSOR 2 CWA31646
(370VAC, 25µF)
0
15 CAPACITOR - FAN MOTOR 1 CWA31289
(450VAC, 3µF)
0
16 ELECTRO MAGNETIC RELAY 2 CWA00010 0
17 RESISTOR 2 CWA46C001 0
18 TERMINAL BOARD 1 CWA28059
19 OVERLOAD PROTECTOR 2 CWA12336 0
20 HOLDER - OVERLOAD PROTECTOR 2 CWH7041200
21 TERMINAL COVER - COMPRESSOR 2 CWH7070204
22 CABIBET TOP PLATE 1 CWE03C026
23 CONTROL BOARD COVER - CABINET 1 CWH13244
24 FRONT PLATE 1 CWE06C110A
25 CABIBET SIDE PLATE 1 CWE04069A
26 FAN GUARD 1 CWD04186A
27 HANDLE 1 CWE16000E
28 SOUND - PROOF MATERIAL 2 CWG30267
29 MOUNT RUBBER - COMPRESSOR 6 CWH50049
30 STRAINER 2 CWB11002
31 OPERATING INSTRUCTION 1 CWF563178
32 INSTALLATION INSTRUCTION 1 CWF612104
33 NUT - COMPRESSOR 6 CWH56000
34 HOLDER CAPACITOR 2 CWH30078
35 NUT TERMINAL COVER 2 CWH7080300
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
The above parts are kept for seven years in accordance with MEI service policy. However, longer lead time will be taken in
supplying the non-numbered parts.
•
“O” marked parts are recommended to be kept in stock.
111
