29 Replacement Parts List
(Note)
•
“O” marked parts are recommended to be kept in stock.
<Model: CU-MC196KE>
NO. DESCRIPTION & NAME Q’TY CU-MC196KE REMARKS
1 BASE ASS’Y 1 CWD50K662A
2 COMPRESSOR A 1 2KS224D5CA02 0
3 MOUNT RUBBER 3 CWH50055
4 NUT 3 CWH4582065
5 SOUND PROOF MATERIAL 1 CWG30915
6 COMPRESSOR B 1 2RS127D3CA04 0
7 MOUNT RUBBER 3 CWH50077
8 NUT 3 CWH56000
9 SOUND PROOF MATERIAL 1 CWG30916
10 OVERLOAD PROTECTOR A 1 CWA12352 0
11 OVERLOAD PROTECTOR B 1 CWA12345 0
12 HOLDER - O.L.P 2 CWH7041200
13 TERMINAL COVER - COMP. 2 CWH171011
14 NUT TERMINAL COVER 2 CWH7080300
15 SOUND PROOF COVER 1 CWH15071
16 CONDENSER 1 CWB32C367
17 COUPLING BRACKET 1 CWH35083A
18 3-WAY VALVE (LIQUID SIDE) 2 CWB01383 0
19 3-WAY VALVE (GAS SIDE) 1 CWB01384 0
20 3-WAY VALVE (GAS SIDE) 1 CWB01486 0
21 CAPILLARY TUBE 1 CWB15672
22 CAPILLARY TUBE 1 CWB15490
23 STRAINER 1 CWB11002
24 FAN MOTOR 1 CWA95394 0
25 FAN MOTOR BRACKET 1 CWD54179
26 PROPELLER FAN 1 CWH00023
27 AIR GUIDER - P. FAN 1 CWD31094A
28 CONTROL BOARD 1 CWH10987
29 ELEC. MAGNETIC RELAY 2 CWA00010 0
30 RESISTOR 2 CWA46C001 0
31 TERMINAL BOARD 1 CWA28059
32 CAPACITOR - COMP. A 1 CWA31647 0
33 CAPACITOR - COMP. B 1 CWA31653 0
34 HOLDER CAPACITOR 2 CWH30057
35 CAPACITOR - FAN MOTOR 1 CWA31289 0
36 FUSE 1 XBA2C31TR0 0
37 FUSE HOLDER 1 XCSCW011
38 CABINET FRONT PLATE 1 CWE06C111A
39 FAN GUARD 1 CWD04183
40 HANDLE 1 CWE16037C
41 CABINET SIDE PLATE 1 CWE04069A
42 CABINET TOP PLATE 1 CWE03C026
43 CONTROL BOARD COVER 1 CWH13244
44 OPERATING INSTRUCTION 1 CWF563178
45 INSTALLATION INSTRUCTION 1 CWF612103
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
117
CS-MC95KE CU-MC145KE / CS-MC95KE CU-MC185KE / CS-MC95KE CU-3MC205KE / CS-MC125KE CU-MC245KE / CS-MC76KE / CS-MC126KE CU-MC196KE
