Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2 × 14 1 × 20
FPI 18 19
Size (W × H × L) mm 624 × 294 × 25.4 687 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(350)
Refrigerant (R-22) g (oz) — 850 (30.0)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — 505
Flow Rate l/min — 17.8
Inner Diameter mm — 1.6
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 440 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400 VAC 1.0 µF, 430 VAC
•
Specifications are subject to change without notice for further improvement.
7
CS-MC95KE CU-MC145KE / CS-MC95KE CU-MC185KE / CS-MC95KE CU-3MC205KE / CS-MC125KE CU-MC245KE / CS-MC76KE / CS-MC126KE CU-MC196KE
