VQT4E90
96
Reference
Specifications
Specifications are subject to change without
notice.
∫ General
Dimensions: 430 mm (W)
59 mm (H)
(excluding the projecting parts)
238 mm (D)
(including the projecting parts)
249 mm (D)
Mass: Approx. 2.8 kg
Power supply: AC 220 to 240 V, 50 Hz
Power consumption: [PWT520] Approx. 28 W
[PWT420] Approx. 27 W
“Power Save in Standby” is activated and
“RF OUT ( Aerial Signal )” is set to “Off”
Approx. 0.2 W
“Power Save in Standby” is not activated
Approx. 3 W
Operating temperature: 5 oC to 40 oC
Operating humidity range: 10 % to 80 % RH
(no condensation)
∫ TV system
Tuner System: DVB-T/DVB-T2
Country: UK
Channel Coverage: UHF 21~68
∫ Video
Video system: PAL/NTSC
Recording system:
MPEG-2, MPEG-4 AVC/H.264
∫ Audio
Recording system:
Dolby Digital (DR mode: Max 5.1ch)
Dolby Digital Plus (DR mode: Max 5.1ch)
MPEG (DR mode: 2ch)
HE-AAC (DR mode: Max 5.1ch (DVB-T/T2))
Audio out: Audio Out L/R (pin jack)
Output level: Full scale: 2.0 Vrms at 1 kHz
Output impedance: Less than 1 k≠
Digital audio out:
Optical terminal
(PCM, Dolby Digital, DTS, MPEG)
HDMI terminal:
(PCM, Dolby Digital, DTS, MPEG,
Dolby Digital Plus, Dolby TrueHD,
DTS-HD Master Audio,
DTS-HD High Resolution Audio)
∫ HDMI Output
19 pin type A: 1 pc.
• This unit supports “HDAVI Control 5”
function.
∫ Internal HDD capacity
[PWT520] 1TB
[PWT420] 500 GB
∫ Other terminals
USB Port (Type A): 2 pcs.
SD Card Slot: 1 pc.
LAN (Ethernet) Port: 1 pc.
10BASE-T/100BASE-TX
∫ [PWT520] Wireless LAN
Standard compliance: IEEE802.11b/g/n
Frequency range: 2.4 GHz band
Security
§
:
WPA™/WPA2™
(Encryption type: TKIP/AES,
Authentication type: PSK)
WEP (64 bit/128 bit)
∫ LASER specification
Class 1 LASER Product
Wave length:
405 nm (BDs)
660 nm (DVDs)
790 nm (CDs)
Laser power:
∫ Region code
DVD: #2
BD: Region B
§
This unit supports WPA and WPA2
encryption.
No hazardous radiation is emitted with
the safety protection
DMR-PWT520&420EB_eng.book 96 ページ ２０１２年３月２３日 金曜日 午後４時４２分
