DMC-TZ7EB/EE/EF/EG/EP/GC/GJ/GN/SG, DMC-ZS3GD/GH/GK/GT/P/PC/PU
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
1 VEP56081C MAIN P.C.B. 1 (RTL) E.S.D. EB,EF,EG,EP B1 XQN16+BJ3FN SCREW 1
1 VEP56081A MAIN P.C.B. 1 (RTL) E.S.D. EE,GC,GJ,GN, B2 VHD2071 SCREW 1
SG,GD,GH,GK,GT,P,PC,PU B3 VHD2071 SCREW 1
2 VEP51024A SUB P.C.B. 1 (RTL) E.S.D. B4 VHD2071 SCREW 1
3 VGQ0C47 PCB SPACER 1 B5 VHD2103 SCREW 1 (-A,-K,-R,-T)
4 L0AA01A00032 SPEAKER 1 B5 VHD2102 SCREW 1 (-S)
5 L0CBAB000129 MICROPHONE U 1 B6 VHD2103 SCREW 1 (-A,-K,-R,-T)
6 VGL1268 AF PANEL LIGHT 1 B6 VHD2102 SCREW 1 (-S)
7 VMP9274 TOP PLATE L 1 B7 VHD2103 SCREW 1 (-A,-K,-R,-T)
8 VMP9275 TOP PLATE R 1 B7 VHD2102 SCREW 1 (-S)
9 VEP50038A TOP OPERATION P.C.B. 1 (RTL) E.S.D. B8 VHD2103 SCREW 1 (-A,-K,-R,-T)
10 VYK3D72 TOP CASE UNIT 1 (DMC-TZ7) B8 VHD2102 SCREW 1 (-S)
10 VYK3D73 TOP CASE UNIT 1 (DMC-ZS3) B9 VHD2103 SCREW 1 (-A,-K,-R,-T)
11 VMP9279 FRAME 1 B9 VHD2102 SCREW 1 (-S)
12 VKF4448 JACK DOOR 1 (-K) B10 VHD2103 SCREW 1 (-A,-K,-R,-T)
12 VKF4447 JACK DOOR 1 (-S) B10 VHD2102 SCREW 1 (-S)
12 VKF4450 JACK DOOR 1 (-T) B11 VHD2103 SCREW 1 (-A,-K,-R,-T)
12 VKF4449 JACK DOOR 1 (-A) B11 VHD2102 SCREW 1 (-S)
12 VKF4551 JACK DOOR 1 (-R) B12 VHD2103 SCREW 1 (-A,-K,-R,-T)
13 VKH0431 STRAP HOLDER 1 B12 VHD2102 SCREW 1 (-S)
14 VMS7893 JACK DOOR SHAFT 1 B13 VHD2103 SCREW 1 (-A,-K,-R,-T)
15 VMS7967 BATTERY DOOR SHAFT 1 B13 VHD2102 SCREW 1 (-S)
16 VYK3D69 BATTERY DOOR ASSY 1 (-K) B14 VHD2103 SCREW 1 (-A,-K,-R,-T)
16 VYK3B82 BATTERY DOOR ASSY 1 (-S) B14 VHD2102 SCREW 1 (-S)
16 VYK3D71 BATTERY DOOR ASSY 1 (-T) B15 VHD2103 SCREW 1 (-A,-K,-R,-T)
16 VYK3D70 BATTERY DOOR ASSY 1 (-A) B15 VHD2102 SCREW 1 (-S)
16 VYK3G61 BATTERY DOOR ASSY 1 (-R) B16 VHD1924 SCREW 1
17 EFN-FSAJ5ZC FLASH U 1 B17 VHD1924 SCREW 1
18 VEP58079A FLASH P.C.B. 1 (RTL) E.S.D. B18 VHD1924 SCREW 1
19 VGQ0C56 SLIDE GUIDE 1 B19 VHD1924 SCREW 1
20 VML3984 SLIDE KNOB 1 B20 XQN16+BJ3FN SCREW 1
21 VWJ2080 FPC 1 B21 XQN16+BJ3FN SCREW 1
22 VYK3D60 FRONT CASE ASSY 1 (-K) B22 XQN16+BJ3FN SCREW 1
22 VYK3B81 FRONT CASE ASSY 1 (-S)
22 VYK3D62 FRONT CASE ASSY 1 (-T)
22 VYK3D61 FRONT CASE ASSY 1 (-A)
22 VYK3G57 FRONT CASE ASSY 1 (-R)
22-1 VGQ0C44 LENS ORNAMENT 1
24 VYK3D48 LCD ASSY 1 201 VMX3650 CCD CUSHION RUBBER 1
25 VYK3D59 LCD PANEL ASSY 1 202 VEK0N77 CCD UNIT 1
31 VYK3F09 REAR CASE ASSY 1 (-K) 203 VDL2318 OPTICAL FILTER 1
31 VYK3F08 REAR CASE ASSY 1 (-S) 204 L6DA8BEC0004 ZOOM MOTOR UNIT 1
31 VYK3F11 REAR CASE ASSY 1 (-T) 207 VDW1786 2nd/3rd DIRECT FRAME 1
31 VYK3F10 REAR CASE ASSY 1 (-A) 208 VXP3172 1st LENS FRAME UNIT 1
31 VYK3G59 REAR CASE ASSY 1 (-R) 210 VXP3178 2nd LENS FRAME UNIT 1
31-1 VGL1293 REAR PANEL LIGHT 1 211 VXP3179 3rd LENS FRAME UNIT 1
31-2 VGU0D99 CURSOR BUTTON 1 214 VXQ1710 MASTER FRANGE UNIT 1
31-3 VGU0E16 ANIMATION BUTTON 1 214-1 L6HA86NC0001 FOCUS MOTOR UNIT 1
32 F2A2F1010008 E.CAPACITOR CH 300V 100U 1 (C8003) 214-2 VMB4251 FOCUS SPRING 1
33 ML-421S/ZTK BUTTON BATTERY 1 (B9901) [ENERGY] 216 VXW1034 LENS UNIT 1
34 VMB4252 EARTH SPRING 1 218 VEK0N75 LENS FPC 1
35 VMB4150 BATTERY DOOR SPRING 1 220 VXP3250 FIX CAM FRAME U 1
36 VMB4232 BATTERY SPRING 1
37 VMP9277 BATTERY CASE 1 B201 VHD1871 SCREW 1
38 VMP9375 EMC PLATE 1 B202 VHD1871 SCREW 1
39 VGQ0C48 TRIPOD 1 B203 VHD1871 SCREW 1
40 VML3983 BATTERY LOCK KNOB 1 B205 XQN14+CJ4FN SCREW 1
41 VMB3962 BATTERY LOCK SPRING 1 B207 VHD2109 SCREW 1
42 VMP9278 EARTH PLATE 1 B211 XQN14+BJ4FNK SCREW 1
43 VMP9319 SCREW PLATE 1 B212 XQN14+BJ4FNK SCREW 1
44 VGQ0G03 DPR SHEET B 1 B213 XQN14+BJ4FNK SCREW 1
45 VGQ0F73 DPR SHEET A 1 B214 XQN14+BJ4FNK SCREW 1
46 VGQ0G29 LCD SPACER 1 B215 XQN14+BJ4FNK SCREW 1
47 VGQ0G36 SPACER SHEET C 1 B216 XQN14+BJ4FNK SCREW 1
48 VGQ0G73 CONDENCER CUSHION 1 B217 XQN14+BJ4FNK SCREW 1
S-17
