Panasonic DMR-EH65EE

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R56117 ERJ2GEJ151X 1/16W 150 1
R56118 ERJ2GEJ820X 1/16W 82 1
R56119 ERJ2GEJ330X 1/16W 33 1
R56120 ERJ2GEJ151X 1/16W 150 1
R56121 ERJ2GEJ151X 1/16W 150 1
R56122 ERJ2GEJ151X 1/16W 150 1
R56123 ERJ2GEJ511X 1/16W 510 1
R56124 ERJ2GEJ103X 1/16W 10K 1
R56125 ERJ2GEJ202X 1/16W 2K 1
R56126 ERJ2GEJ202X 1/16W 2K 1
R56127 ERJ2GEJ103X 1/16W 10K 1
R56128 ERJ2GEJ202X 1/16W 2K 1
R56129 ERJ2GEJ202X 1/16W 2K 1
R56130 ERJ2GEJ273X 1/16W 27K 1
R56131 ERJ2GEJ221X 1/16W 220 1
R56132 ERJ2GEJ224X 1/16W 220K 1
R56133 ERJ2GEJ104X 1/16W 100K 1
R56134 ERJ2GEJ470X 1/16W 47 1
R56135 ERJ2GEJ470X 1/16W 47 1
R56137 ERJ2GE0R00X 1/16W 0 1
R56138 ERJ2GE0R00X 1/16W 0 1
R56139 ERJ2GEJ820X 1/16W 82 1
R56140 ERJ2GEJ8R2X 1/16W 8.2 1
R56142 ERJ2GEJ330X 1/16W 33 1
R56143 ERJ2GEJ330X 1/16W 33 1
R56144 ERJ2GEJ8R2X 1/16W 8.2 1
R56145 ERJ2GEJ8R2X 1/16W 8.2 1
R56146 ERJ2GEJ8R2X 1/16W 8.2 1
R56147 ERJ2GEJ8R2X 1/16W 8.2 1
R56148 ERJ2GEJ8R2X 1/16W 8.2 1
R56149 ERJ2GEJ8R2X 1/16W 8.2 1
R56150 ERJ2GEJ8R2X 1/16W 8.2 1
R56151 ERJ2GEJ820X 1/16W 82 1
R56152 ERJ2GEJ820X 1/16W 82 1
R56153 ERJ2GEJ820X 1/16W 82 1
R56154 ERJ2GEJ820X 1/16W 82 1
R56155 ERJ2GEJ820X 1/16W 82 1
R56156 ERJ2GEJ820X 1/16W 82 1
R56157 ERJ2GEJ820X 1/16W 82 1
R56158 ERJ2GEJ152X 1/16W 1.5K 1
R56159 ERJ2GEJ332X 1/16W 3.3K 1
R56160 ERJ2GEJ223X 1/16W 22K 1
R56161 ERJ2GEJ470X 1/16W 47 1
RX56101 D1H83304A024 RESISTOR-RESISTOR 1
RX56102 D1H83304A024 RESISTOR-RESISTOR 1
VA56101 D4ED13900002 VARISTOR 1
VA56102 D4ED13900002 VARISTOR 1
VA56103 EZJZ0V800AA VERIABLE RESISTOR 1
VA56104 D4ED13900002 VARISTOR 1
VA56105 EZJZ0V800AA VERIABLE RESISTOR 1
VA56106 D4ED13900002 VARISTOR 1
VA56107 EZJZ0V800AA VERIABLE RESISTOR 1
VA56108 D4ED13900002 VARISTOR 1
VA56109 EZJZ0V800AA VERIABLE RESISTOR 1
VA56110 D4ED13900002 VARISTOR 1
VA56111 EZJZ0V800AA VERIABLE RESISTOR 1
VA56112 D4ED13900002 VARISTOR 1
VA56113 D4ED13900002 VARISTOR 1
n
nn
n VEP73135A DV JACK P.C.B. (RTL)
P37001 K1KA06B00181 CONNECTOR(6P) 1
P37002 K2HZ104B0012 CONNECTOR(104P) 1
n
nn
n CASING/ACCESSORY/P
ACKING
1 VEP70161A FRONT(L) P.C.B. 1 (RTL)
2 VEP73135A DV JACK P.C.B. 1 (RTL)
3 RFKB79119MT MAIN P.C.B. 1 EE
3 RFKB79119NT MAIN P.C.B. 1 GC,GCS,GN
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
5 RGR0365C-D1 REAR PANEL 1 EE
5 RGR0365C-G1 REAR PANEL 1 GC
5 RGR0365C-F1 REAR PANEL 1 GCS
5 RGR0365C-E1 REAR PANEL 1 GN
6 RHD30111-3J SCREW 20
7 RHD30119-L SCREW 16
8 RMA1979A DIGITAL ANGLE A 1
9 RFKNEH65EE RAM/DIGITAL P.C.B.
MODULE
1 EE
9 RFKNEH65GC RAM/DIGITAL P.C.B.
MODULE
1 GC
9 RFKNEH65GCS RAM/DIGITAL P.C.B.
MODULE
1 GCS
9 RFKNEH65GN RAM/DIGITAL P.C.B.
MODULE
1 GN
10 RMQ1513 HEAT TRANSFER
SHEET
1
11 L6FAJDAE0001 FAN MOTOR 1
12 RKA0186-K FOOT RUBBER 4
13 RMC0672 PLATE SPRING 1
14 RMY0357 HEAT SINK 1
15 RHD32001 SCREW 4
16 VKC0295 NYLON RIVET 2
17 RMQ1514 HEAT TRANSFER
SHEET D
1
18 RYP1320A-S FRONT PANEL ASS’Y
1
1 EE
18 RYP1320C-S FRONT PANEL ASS’Y
1
1 GC,GCS
18 RYP1320B-S FRONT PANEL ASS’Y
1
1 GN
18-1 RGK1968C-Q FL ORNAMENT 1
18-2 RGK1971A-S REC BUTTON RING 1
18-3 RYF0798K-S PANEL DOOR ASS’Y 1
18-4 RKF0751C-K TRAY DOOR 1
18-5 VMB3410 BLINDER SPRING 1
18-6 RHD26045 SCREW 2
18-7 RKF0754-K SD BLINDER 1
18-8 RMB0841-1 SD LID SPRING 1
18-9 RMR1767-K SD CHASSIS 1
19 RHD30113 SCREW 2
20 RFKV0071HDK HDD 250GB 1
21 RKM0552A-S TOP CASE 1
22 RMN0841 HDD BRACKET 1
23 RMC0625 TUNER END 2
24 RKA0184-K LEG SHEET 1
25 VEK0J99 HDD POWER CABLE 1
26 VEP73137A HDMI P.C.B. 1 (RTL)
28 VEP71110A POWER SUPPLY
P.C.B.
1 (RTL)
29 VEP07A91D TUNER P.C.B. 1 (RTL)
30 XSN3+4FJ SCREW 2
31 RMQ1551 GASKET A 1
32 VMX1336 MINI CARD SPACER 1
33 VEK0K02 FFC(40P) 1
34 VEP73136A SD CARD P.C.B. 1 (RTL)
36 VEK0K01 FFC(20P) 1
37 N5EZZ0000003 HDD CONNECTOR 1
39 RMR1766-K SD CARD HOLDER
ASS’Y
1
40 XTN2+8GFJ SCREW 2
41 RMV0312 SHEET COVER 1
44 VEK0K15 FFC(40P) 1
46 VMC1534 EARTH SPRING 2
47 XYN3+J8FJ SCREW 2
A1 EUR7659YC0 REMOTE CONTROL
ASS’Y
1 EE
A1 EUR7659YE0 REMOTE CONTROL
ASS’Y
1 GC,GCS
A1 EUR7659YD0 REMOTE CONTROL
ASS’Y
1 GN
A1-1 UR76EC5903A BATTERY COVER 1
A2 K2CR2DA00004 AC CORD 1 EE,GC,GCS
A2 K2CT3CA00004 AC CORD 1 GC
A2 K2CJ2DA00008 AC CORD 1 GN
100
DMR-EH65EE / DMR-EH65GC / DMR-EH65GCS / DMR-EH65GN
