Panasonic DMR-EH65EE

16.2. Replacement Parts List
Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
*“(IA)-(IE)”, marks in Remarks indicate languages of
instruction manuals. [(IA): English, (IB): Chinese, (IC):
Arabic, (ID): Russian, (IE): Ukrainian]
*Parts indicated with PAVC-CSG in the Remarks column
are supplied by PAVC-CSG.
*All parts except parts indicated with (PAVC-CSG) in the
Remarks column are supplied by PAVCSG.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
n
nn
n RFKB79119MT MAIN P.C.B. (RTL)EE
n
nn
n RFKB79119NT MAIN P.C.B. (RTL)GC,GCS,G
N
C1503 F2A1A6810022 10V 680P 1
C1504 F2A1E1010067 25V 100U 1
C1508 F1H1A105A028 10V 1U 1
C1509 ECJ1VB1H103K 50V 0.01U 1
C1510 F1H1A105A028 10V 1U 1
C1511 F1H1A105A028 10V 1U 1
C1512 F1H1A105A028 10V 1U 1
C1515 F2A1E4700048 25V 47U 1
C1516 F2A1H1510006 50V 150P 1
C1518 F2A0J6810007 6.3V 680P 1
C1519 F1H1A105A028 10V 1U 1
C1520 F1H1A105A028 10V 1U 1
C1521 F2A1C121A453 16V 120P 1
C1522 F1H1A105A028 10V 1U 1
C1523 F2A1A470A388 10V 47U 1
C1524 F2A1A101A389 10V 100U 1
C1525 ECJ1VB1C104K 16V 0.1U 1
C1526 F1H1A105A028 10V 1U 1
C1527 F1H1A105A028 10V 1U 1
C1528 F1K1C105A026 16V 1U 1
C1529 F2A1A470A388 10V 47U 1
C1535 F1H1A105A028 10V 1U 1
C1536 F1J0J106A014 6.3V 10U 1
C1538 F1H1A105A028 10V 1U 1
C1539 F1H1A105A028 10V 1U 1
C1540 ECJ1VB1H103K 50V 0.01U 1
C1541 F2A1E1010067 25V 100U 1
C1548 F2A1C121A453 16V 120P 1
C1549 F2A1C121A453 16V 120P 1
C3001 ECJ1VB1C104K 16V 0.1U 1
C3002 ECJ1VB1H103K 50V 0.01U 1
C3003 ECJ1VB1C104K 16V 0.1U 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C3004 ECJ1VB1C104K 16V 0.1U 1
C3005 ECA0JM471B 6.3V 470U 1
C3006 ECA0JM471B 6.3V 470U 1
C3007 F2A1A4710038 10V 470U 1
C3008 F2A1A1010072 10V 100U 1
C3009 F2A1A4710038 10V 470U 1
C3010 F2A1A1010072 10V 100U 1
C3011 ECJ1VB1C104K 16V 0.1U 1
C3012 F2A1A4710038 10V 470U 1
C3013 F2A1A1010072 10V 100U 1
C3014 ECJ1VB1C104K 16V 0.1U 1
C3015 ECJ1VB1C104K 16V 0.1U 1
C3016 ECJ1VB1C104K 16V 0.1U 1
C3017 ECJ1VB1C104K 16V 0.1U 1
C3018 ECJ1VB1C104K 16V 0.1U 1
C3019 ECJ1VB1C104K 16V 0.1U 1
C3020 ECJ1VB1C104K 16V 0.1U 1
C3021 ECJ1VB1C104K 16V 0.1U 1
C3022 ECJ1VB1C104K 16V 0.1U 1
C3024 ECJ1VB0J105K 6.3V 1U 1
C3025 ECJ1VB1C104K 16V 0.1U 1
C3026 ECJ1VB0J105K 6.3V 1U 1
C3027 ECJ1VB1C104K 16V 0.1U 1
C3028 ECJ1VB0J105K 6.3V 1U 1
C3029 ECJ1VB1C104K 16V 0.1U 1
C3031 ECJ1VB1H103K 50V 0.01U 1
C3032 ECEA0JKA101B 6.3V 100U 1
C3033 ECJ1VB1H103K 50V 0.01U 1
C3034 ECJ1VB1H103K 50V 0.01U 1
C3035 ECEA0JKA101B 6.3V 100U 1
C3038 ECJ1VB1C104K 16V 0.1U 1
C3039 ECJ1VB1C104K 16V 0.1U 1
C3041 ECJ1VC1H330J 50V 33P 1
C3057 ECJ1VB1H102K 50V 1000P 1
C3058 ECJ1VC1H471J 50V 470P 1
C3059 ECJ1VB1H102K 50V 1000P 1
C3060 ECJ1VC1H471J 50V 470P 1
C3064 ECJ1VB1C104K 16V 0.1U 1
C3070 ECJ1VB1H102K 50V 1000P 1
C3071 ECJ1VB1H102K 50V 1000P 1
C3072 ECJ1VB1C104K 16V 0.1U 1
C3910 F2A1V100A534 35V 10U 1
C3911 F2A1V100A534 35V 10U 1
C3914 F2A1H100A236 50V 10U 1
C3915 F2A1H100A236 50V 10U 1
C3916 F2A1H1R0A236 50V 1U 1
C3917 F2A1H1R0A236 50V 1U 1
C3918 F2A1H100A236 50V 10U 1
C3919 F2A1H100A236 50V 10U 1
C3928 F2A1H1R0A638 50V 1U 1
C3929 F2A1H1R0A638 50V 1U 1
C3935 F2A1E2210050 25V 220U 1
C3953 ECJ1VC1H471J 50V 470P 1
C3954 ECJ1VC1H471J 50V 470P 1
C3955 ECJ1VC1H221J 50V 220P 1
C3956 ECJ1VC1H221J 50V 220P 1
C3957 ECJ1VC1H471J 50V 470P 1
C3958 ECJ1VC1H471J 50V 470P 1
C3961 ECJ1VC1H221J 50V 220P 1
C3962 ECJ1VC1H221J 50V 220P 1
C4003 ECJ1VB0J105K 6.3V 1U 1
C4005 F2A1V100A534 35V 10U 1
C4006 F2A1V100A534 35V 10U 1
C4008 F2A1E1010067 25V 100U 1
C4019 F2A1C100A796 16V 10P 1
C4021 F2A1C100A796 16V 10P 1
C4023 F2A1H1R0A638 50V 1U 1
C4024 F2A1E1010067 25V 100U 1
C4025 F2A1H1R0A638 50V 1U 1
C4027 F2A1V100A534 35V 10U 1
C4028 F2A1V100A534 35V 10U 1
C4033 F2A1C220B173 16V 22P 1
C4034 F2A1C220B173 16V 22P 1
93
DMR-EH65EE / DMR-EH65GC / DMR-EH65GCS / DMR-EH65GN
