15.1.5. P59001 Connector
Ref No.
MODE 1234567891011121314151617181920
REC 0000000000003.312.3 4.9 12.3 3.3 0 4.9 0
PLAY 0000000000003.312.3 4.9 12.3 3.3 0 4.9 0
STOP 0000000000003.312.3 4.9 12.3 3.3 0 4.9 0
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
REC 3.3 5.1 3.3 5.1 5.0 3.3 2.3 3.1 2.5 4.9 2.5 3.3 0 3.3 0 3.3 0 3.3 2.5 -
PLAY 3.3 5.1 3.3 5.1 5.0 3.3 2.3 3.1 2.5 4.9 2.5 3.3 0 3.3 0 3.3 0 3.3 2.5 -
STOP 3.3 5.1 3.3 5.1 5.0 3.3 2.3 3.2 2.5 4.9 2.5 3.3 0 3.3 0 3.3 0 3.3 2.5 -
Ref No.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
REC 2.5 3.2 0 1.7 0 0 0 3.3 0 3.3 1.1 - 0 0.3 1.5 3.3 0 - 1.0 4.8
PLAY 2.5 3.2 0 1.7 0 0 0 3.3 0 3.3 1.1 - 0 0.3 1.5 3.3 0 - 1.0 4.8
STOP 2.5 3.2 0 1.7 0 0 0 3.3 0 3.3 1.1 - 0 0.3 1.5 3.3 0 - 1.0 4.8
Ref No.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
REC 0 4.8 1.1 12.3 0 12.3 1.0 12.3 0 12.3 1.3 12.3 0 12.3 2.1 5.0 0 0 - -
PLAY 0 4.8 1.1 12.3 0 12.3 1.0 12.3 0 12.3 1.3 12.3 0 12.3 2.1 5.0 0 0 - -
STOP 0 4.8 1.1 12.3 0 12.3 1.0 12.3 0 12.3 1.3 12.3 0 12.3 2.1 5.0 0 0 - -
Ref No.
MODE 81 82 83 84 85 86 87 88
REC 0000.30000
PLAY 0000.30000
STOP 0000.30000
P59001
P59001
P59001
P59001
P59001
87
