Panasonic DMR-EH65EE

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
IC7501 C2CBJG000728 IC 1
IC7502 C0EBE0000504 IC 1
IC7504 C0HBB0000044 IC 1
IC7505 C0EBJ0000336 IC 1
IC7507 C0ABBA000073 IC 1
IP1501 K5H302100004 IC PROTECTOR 1
IP7501 K5H7512A0010 IC PROTECTOR 1
IR7501 PNA4618M09VT REMOTE SENSOR 1
JK3001 K1U822B00003 JACK,OUT,AV4 IN 1
JK3002 K2HE1YYB0002 JACK,AV3 1
JK3901 K1FB242B0005 JACK,AV1,AV2 1
JK3903 K2HA306B0085 JACK,COMPONENT
VIDEO OUT
1
JW7501 VWJ02F0060VV MAIN/FRONT CABLE
UNIT
1
K7303 ERJ3GEY0R00V 1/10W 0 1
K7308 ERJ3GEY0R00V 1/10W 0 1
K7503 ERJ3GEY0R00V 1/10W 0 1
K7504 ERJ3GEY0R00V 1/10W 0 1
L1505 G0A100HA0023 COIL 10UH 1
L4901 G0C220KA0065 COIL 22UH 1
L7303 G0C1R0JA0019 COIL 1UH 1
L7304 G0C2R2JA0019 COIL 2.2UH 1
L7401 G0A220GA0026 COIL 22UH 1
L7402 G0A220GA0026 COIL 22UH 1
L7501 G0C390JA0055 COIL 39UH 1
L7502 G0C220JA0019 COIL 22UH 1
LB1502 J0JKB0000003 COIL 1
LB1503 J0JKB0000003 COIL 1
LB1504 J0JKB0000003 COIL 1
LB1506 J0JKB0000003 COIL 1
LB3001 J0JGC0000020 COIL 1
LB3002 J0JGC0000020 COIL 1
LB3003 J0JGC0000020 COIL 1
LB3005 J0JBC0000011 COIL 1
LB3006 J0JBC0000019 COIL 1
LB3007 J0JBC0000011 COIL 1
LB3008 J0JBC0000019 COIL 1
LB3009 ERJ3GEY0R00V 1/10W 0 1
LB3010 ERJ3GEY0R00V 1/10W 0 1
LB3011 ERJ3GEY0R00V 1/10W 0 1
LB3012 J0JBC0000011 COIL 1
LB3013 J0JBC0000011 COIL 1
LB3907 J0JBC0000011 COIL 1
LB3908 J0JBC0000011 COIL 1
LB3911 J0JGC0000020 COIL 1
LB3912 J0JBC0000011 COIL 1
LB3913 J0JBC0000011 COIL 1
LB7301 J0JCC0000124 COIL 1
LB7302 J0JCC0000124 COIL 1
LB7303 J0JCC0000080 COIL 1
LB7304 J0JHC0000032 COIL 1
LB7401 J0JGC0000020 COIL 1
LB7402 J0JKB0000012 COIL 1
LB7403 J0JKB0000012 COIL 1
LB7404 J0JKB0000012 COIL 1
LB7405 J0JKB0000012 COIL 1
LB7406 J0JCC0000164 COIL 1
LB7407 J0JKB0000012 COIL 1
LB7408 J0JCC0000164 COIL 1
LB7409 J0JKB0000012 COIL 1
LB7410 J0JCC0000103 COIL 1
LB7411 J0JCC0000164 COIL 1
LB7412 J0JCC0000164 COIL 1
LB7413 J0JCC0000164 COIL 1
LB7414 J0JCC0000164 COIL 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
LB7415 J0JCC0000103 COIL 1
LB7416 J0JCC0000164 COIL 1
LB7417 J0JCC0000103 COIL 1
LB7418 J0JCC0000103 COIL 1
LB7419 J0JCC0000103 COIL 1
LB7420 J0JCC0000164 COIL 1
LB7501 ERJ3GEY0R00V 1/10W 0 1
LB7502 ERJ3GEY0R00V 1/10W 0 1
LB7507 ERJ3GEY0R00V 1/10W 0 1
LB7508 ERJ3GEY0R00V 1/10W 0 1
LB7509 J0JCC0000060 COIL 1
LB7510 ERJ3GEY0R00V 1/10W 0 1
LB7515 ERJ3GEY0R00V 1/10W 0 1
LB7516 ERJ3GEY0R00V 1/10W 0 1
LB7517 ERJ3GEY0R00V 1/10W 0 1
P1501 K1KA23A00003 CONNECTOR(23P) 1
P1503 K1KA04AA0301 CONNECTOR(4P) 1
P7402 K1KA88A00002 CONNECTOR(88P) 1
P7505 K1KY10AA0107 CONNECTOR(10P) 1
PP7401 K1KA18AA0288 CONNECTOR(18P) 1
Q1501 B1DHED000008 TRANSISTOR 1
Q1509 B1DHED000008 TRANSISTOR 1
Q4006 2SD132800L TRANSISTOR 1
Q4007 2SD132800L TRANSISTOR 1
Q4008 2SD132800L TRANSISTOR 1
Q4009 2SD132800L TRANSISTOR 1
Q7401 2SD1819ARL TRANSISTOR 1
Q7402 2SD1819A0L TRANSISTOR 1
Q7501 2SB1218A0L TRANSISTOR 1
Q7502 2SD1819A0L TRANSISTOR 1
Q7503 2SB1218A0L TRANSISTOR 1
Q7504 2SD1819A0L TRANSISTOR 1
Q7505 2SD0601A0L TRANSISTOR 1
Q7506 2SD0601A0L TRANSISTOR 1
Q7507 2SD0601A0L TRANSISTOR 1
Q7508 2SD1819A0L TRANSISTOR 1
Q7509 2SD0601A0L TRANSISTOR 1
Q7510 B1BABK000001 TRANSISTOR 1
Q7511 B1ABMD000004 TRANSISTOR 1
QR1501 UNR521300L TRANSISTOR 1
QR1503 UNR521300L TRANSISTOR 1
QR4002 UNR511100L TRANSISTOR 1
QR4003 UNR521100L TRANSISTOR 1
QR4004 UNR521100L TRANSISTOR 1
QR7401 UNR521300L TRANSISTOR 1
QR7402 UNR511200L TRANSISTOR 1
QR7403 UNR521500L TRANSISTOR 1
QR7404 UNR521500L TRANSISTOR 1
QR7507 UNR521000L TRANSISTOR 1
QR7508 UNR521400L TRANSISTOR 1
R1502 ERJ3GEYJ103V 1/10W 10K 1
R1505 ERJ3GEYJ823V 1/10W 82K 1
R1506 ERJ3GEYJ222V 1/10W 2.2K 1
R1507 ERJ3GEYJ822V 1/10W 8.2K 1
R1509 ERJ3RBD393V 1/16W 39K 1
R1510 ERJ3RBD113V 1/16W 11K 1
R1511 ERJ3RBD152V 1/16W 1.5K 1
R1518 ERJ3GEYJ223V 1/10W 22K 1
R1519 ERJ3GEYJ223V 1/10W 22K 1
R3001 ERJ3GEYJ102V 1/10W 1K 1
R3003 ERJ3GEYJ102V 1/10W 1K 1
R3004 ERJ3GEYJ102V 1/10W 1K 1
R3006 ERJ3GEY0R00V 1/10W 0 1
R3007 ERJ3GEYJ330V 1/10W 33 1
R3008 ERJ3GEYJ102V 1/10W 1K 1
R3009 ERJ3GEYJ104V 1/10W 100K 1
R3054 ERJ3GEYJ750V 1/10W 75 1
R3055 ERJ3GEYJ750V 1/10W 75 1
95
DMR-EH65EE / DMR-EH65GC / DMR-EH65GCS / DMR-EH65GN
