Panasonic DMR-EH65EE

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R7571 ERJ3GEYJ101V 1/10W 100 1
R7572 ERJ3GEYJ101V 1/10W 100 1
R7574 ERJ3GEYJ223V 1/10W 22K 1
R7575 ERJ3GEYJ101V 1/10W 100 1
R7576 ERJ3GEYJ102V 1/10W 1K 1
R7577 ERJ3GEYJ103V 1/10W 10K 1
R7579 ERJ3GEYJ223V 1/10W 22K 1
R7582 ERJ3GEYJ104V 1/10W 100K 1
R7583 ERJ3GEYJ472V 1/10W 4.7K 1
R7584 ERJ3GEYJ473V 1/10W 47K 1
R7585 ERJ3GEYJ225V 1/10W 2.2M 1
R7586 ERJ3GEYJ273V 1/10W 27K 1
R7587 ERJ3GEYJ224V 1/10W 220K 1
R7588 ERJ3GEYJ104V 1/10W 100K 1
R7589 ERJ3GEYJ221V 1/10W 220 1
R7590 ERJ3GEYJ104V 1/10W 100K 1
R7597 ERJ3GEYJ822V 1/10W 8.2K 1
R7598 ERJ3GEYJ822V 1/10W 8.2K 1
R7599 ERJ3GEYJ822V 1/10W 8.2K 1
R7600 ERJ3GEYJ103V 1/10W 10K 1
R7601 ERJ3GEYJ102V 1/10W 1K 1
R7606 ERJ3GEYF393V 1/10W 39K 1
R7607 ERJ3GEYJ101V 1/10W 100 1
R7608 ERJ3GEYF433V 1/10W 43K 1
R7612 ERJ3GEYJ562V 1/10W 5.6K 1
R7614 ERJ3GEYJ470V 1/10W 47 1
R7615 ERJ3GEYJ473V 1/10W 47K 1
R7616 ERJ3GEYJ473V 1/10W 47K 1
R7617 ERDS2TJ271T 1/4W 270 1
R7619 ERJ3GEYJ103V 1/10W 10K 1
R7621 ERJ3GEYJ104V 1/10W 100K 1
R7623 ERJ3GEYJ181V 1/10W 180 1
R7624 ERJ3GEYJ103V 1/10W 10K 1
R7625 ERJ3GEYJ103V 1/10W 10K 1
R7626 ERJ3GEYJ821V 1/10W 820 1
R7627 ERJ3GEYJ303V 1/10W 30K 1
R7639 ERJ3GEYJ272V 1/10W 2.7K 1
R7640 ERJ3GEYJ272V 1/10W 2.7K 1
R7641 ERJ3GEYJ272V 1/10W 2.7K 1 EE
R7642 ERJ3GEYJ562V 1/10W 5.6K 1
R7643 ERJ3GEYJ163V 1/10W 16K 1
R7644 ERJ3GEYJ562V 1/10W 5.6K 1
R7648 ERDS2TJ470T 1/4W 47 1
R7651 ERJ3GEYJ472V 1/10W 4.7K 1
R7653 ERJ3GEYJ101V 1/10W 100 1
R7655 ERJ3GEYJ101V 1/10W 100 1
S7501 EVQ11A04M SWITCH,EXT LINK 1 EE
S7502 EVQ11A04M SWITCH,CH DOWN 1
S7503 EVQ11A04M SWITCH,CH UP 1
S7504 EVQ11A04M SWITCH,OPEN/CLOSE 1
S7505 EVQ11A04M SWITCH,SELECT 1
S7506 EVQ11A04M SWITCH,STOP 1
S7507 EVQ11A04M SWITCH,PLAY 1
S7508 EVQ11A04M SWITCH,REC 1
T7501 G4D1A0000117 TRANSFORMER 1
W501 ERJ3GEY0R00V 1/10W 0 1
W502 ERJ3GEY0R00V 1/10W 0 1
W503 ERJ3GEY0R00V 1/10W 0 1
W504 ERJ3GEY0R00V 1/10W 0 1
W505 ERJ3GEY0R00V 1/10W 0 1
W506 ERJ3GEY0R00V 1/10W 0 1
W507 ERJ3GEY0R00V 1/10W 0 1
W508 ERJ3GEY0R00V 1/10W 0 1
W509 ERJ3GEY0R00V 1/10W 0 1
W510 ERJ3GEY0R00V 1/10W 0 1
W511 ERJ3GEY0R00V 1/10W 0 1
W512 ERJ3GEY0R00V 1/10W 0 1
W513 ERJ3GEY0R00V 1/10W 0 1
W514 ERJ3GEY0R00V 1/10W 0 1
W515 ERJ3GEY0R00V 1/10W 0 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
W516 ERJ3GEY0R00V 1/10W 0 1
W517 ERJ3GEY0R00V 1/10W 0 1
W518 ERJ3GEY0R00V 1/10W 0 1
W519 ERJ3GEY0R00V 1/10W 0 1
W520 ERJ3GEY0R00V 1/10W 0 1
W521 ERJ3GEY0R00V 1/10W 0 1
W522 ERJ3GEY0R00V 1/10W 0 1
W523 ERJ3GEY0R00V 1/10W 0 1
W524 ERJ3GEY0R00V 1/10W 0 1
W525 ERJ3GEY0R00V 1/10W 0 1
W527 ERJ3GEY0R00V 1/10W 0 1
W528 ERJ3GEY0R00V 1/10W 0 1
W529 ERJ6GEY0R00V 1/8W 0 1
W530 ERJ6GEY0R00V 1/8W 0 1
W531 ERJ6GEY0R00V 1/8W 0 1
W532 ERJ6GEY0R00V 1/8W 0 1
W533 ERJ6GEY0R00V 1/8W 0 1
W534 ERJ3GEY0R00V 1/10W 0 1
W535 ERJ3GEY0R00V 1/10W 0 1
W536 ERJ3GEY0R00V 1/10W 0 1
W537 ERJ3GEY0R00V 1/10W 0 1
W538 ERJ3GEY0R00V 1/10W 0 1
X7301 H0D245500016 CRYSTAL OSCILLATOR 1
X7501 H0D100500018 CRYSTAL OSCILLATOR 1
X7502 H0A327200108 CRYSTAL OSCILLATOR 1
n
nn
n VEP07A91D TUNER P.C.B. (RTL)
C7809 ECJ1VB1H103K 50V 0.01U 1
C7813 F2A0J470A599 6.3V 47U 1
C7814 F2A1H2200032 50V 22U 1
C7817 F2A0J470A599 6.3V 47U 1
C7818 ECJ1VC1H330J 50V 33P 1
C7819 ECJ1VC1H330J 50V 33P 1
C7820 ECJ1VB1C104K 16V 0.1U 1
C7821 ECJ1VB1H103K 50V 0.01U 1
C7822 ECJ1VB1H103K 50V 0.01U 1
C7824 F2A0J470A599 6.3V 47U 1
C7825 ECJ1VC1H101J 50V 100P 1
C7828 ECJ1VB1H103K 50V 0.01U 1
D7802 B0BA03000015 DIODE 1
K7808 ERJ3GEY0R00V 1/10W 0 1
K7810 ERJ3GEY0R00V 1/10W 0 1
LB7802 J0JHC0000032 COIL 1
LB7803 J0JHC0000032 COIL 1
LB7804 J0JHC0000032 COIL 1
PS7801 K1KB18B00012 CONNECTOR(18P) 1
Q7802 2SB1218A0L TRANSISTOR 1
R7811 ERDS2TJ102T 1/4W 1K 1
R7812 ERJ6GEYJ681V 1/8W 680 1
R7815 ERJ3GEYJ471V 1/10W 470 1
R7816 ERJ3GEYJ471V 1/10W 470 1
R7818 ERJ3GEYJ221V 1/10W 220 1
R7820 ERJ3GEYJ102V 1/10W 1K 1
R7844 ERJ6GEYJ681V 1/8W 680 1
TU7801 ENGF7502GF TUNER 1
W501 ERJ6GEY0R00V 1/8W 0 1
W502 ERJ3GEY0R00V 1/10W 0 1
W503 ERJ6GEY0R00V 1/8W 0 1
W504 ERJ6GEY0R00V 1/8W 0 1
W505 ERJ6GEY0R00V 1/8W 0 1
W506 ERJ3GEY0R00V 1/10W 0 1
W507 ERJ3GEY0R00V 1/10W 0 1
W508 ERJ6GEY0R00V 1/8W 0 1
97
DMR-EH65EE / DMR-EH65GC / DMR-EH65GCS / DMR-EH65GN
