Panasonic DMR-EZ28P

Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
*“(IA), (IB)”, marks in Remarks indicate language of
instruction manuals. [(IA): English, (IB): Canadian French]
*All parts are supplied by PAVCSG.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
Q VEP79179A MAIN P.C.B. 1 (RTL)(P)
Q VEP79179B MAIN P.C.B. 1 (RTL)(PC)
C1101 ECQU2A683MLC 0.068U 1
C1102 F1B2G1020002 1000P 1
C1103 F1B2G1020002 1000P 1
C1104 ECQU2A223MLC 0.022U 1
C1107 F2B2E1510004 250V 150U 1
C1108 F1B2G1020002 1000P 1
C1120 F2A1V5600013 35V 56U 1
C1121 F1B3A182A009 250V 1800P 1
C1122 ECJ1VB1H102K 50V 1000P 1
C1123 ECJ1VC1H101J 50V 100P 1
C1124 F1H1H222A798 50V 2200P 1
C1201 ECJ1VB1A224K 10V 0.22U 1
C1203 ECJ1VB1C473K 16V 0.047U 1
C1210 F2A1A5610008 10V 560U 1
C1211 F2A1A1010072 10V 100U 1
C1220 F2A1C8210008 16V 820U 1
C1221 F2A1E2210050 25V 220U 1
C1230 F2A1A1820007 10V 1800U 1
C1231 F2A1A6810022 10V 680U 1
C1250 F2A1E2210067 25V 220 1
C1251 F1H1C105A095 16V 1U 1
C1252 F1H1C104A090 16V 0.1U 1
C1253 F1H1C104A090 16V 0.1U 1
C1254 ECJ1VC1H270J 50V 27P 1
C1256 ECJ1VB1H103K 50V 0.01U 1
C1258 F2A1A6810022 10V 680U 1
C1262 F2A1A1010072 10V 100U 1
C1263 F2A1A1010072 10V 100U 1
C1320 F1H1A105A028 10V 1U 1
C1321 F1H1A105A028 10V 1U 1
C1322 ECJ1VB1H103K 50V 0.01U 1
C1330 F1H1A105A028 10V 1U 1
C1331 F1H1A105A028 10V 1U 1
C1342 F2A1A1010072 10V 100U 1
C1343 ECJ1VB1C333K 16V 0.033U 1
C1344 F2A1A1010072 10V 100U 1
C1350 F1H1A105A028 10V 1U 1
C1351 F2A1A1010072 10V 100U 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C1353 ECJ1VB1H103K 50V 0.01U 1
C1361 F2A1A1010072 10V 100U 1
C1362 ECJ1VB1C333K 16V 0.033U 1
C1363 F2A1A1010072 10V 100U 1
C3003 F1H1C104A090 16V 0.1U 1
C3004 ECJ1VB1H103K 50V 0.01U 1
C3005 ECJ1VB0J105K 6.3V 1U 1
C3006 F2A1C100B110 16V 10P 1
C3007 F1H1C104A090 16V 0.1U 1
C3008 ECJ1VB0J105K 6.3V 1U 1
C3009 ECJ1VB0J105K 6.3V 1U 1
C3010 ECJ1VB0J105K 6.3V 1U 1
C3011 ECJ1VB0J105K 6.3V 1U 1
C3012 ECJ1VB0J105K 6.3V 1U 1
C3013 ECJ1VB0J105K 6.3V 1U 1
C3014 ECJ1VB1H103K 50V 0.01U 1
C3015 ECJ1VB0J105K 6.3V 1U 1
C3016 F1H1C104A090 16V 0.1U 1
C3017 ECJ1VB1H103K 50V 0.01U 1
C3018 F1H1C104A090 16V 0.1U 1
C3019 ECJ1VB1H103K 50V 0.01U 1
C3020 F2A1C470B110 16V 47U 1
C3021 F2A1C470B110 16V 47U 1
C3022 F1H1C104A090 16V 0.1U 1
C3023 F1H1C104A090 16V 0.1U 1
C3024 F2A0J471A832 6.3V 470U 1
C3025 F2A0J471A832 6.3V 470U 1
C3026 F2A0J102A833 6.3V 1000P 1
C3027 F2A0J102A833 6.3V 1000P 1
C3028 F2A0J102A833 6.3V 1000P 1
C3029 F1H1C104A090 16V 0.1U 1
C3030 ECJ1VB1H103K 50V 0.01U 1
C3031 ECJ1VB0J105K 6.3V 1U 1
C3032 ECJ1VB1H103K 50V 0.01U 1
C3033 F1H1C104A090 16V 0.1U 1
C4001 F2A1H1R0B032 50V 1U 1
C4002 F2A1H1R0B032 50V 1U 1
C4003 F2A1H1R0B032 50V 1U 1
C4004 F2A1H1R0B032 50V 1U 1
C4005 ECJ1VB1C105K 16V 1U 1
C4006 ECJ1VB1C105K 16V 1U 1
C4007 F2A1H4R7B040 50V 4.7U 1
C4008 ECJ1VC1H101J 50V 100P 1
C4009 ECJ1VC1H101J 50V 100P 1
C4010 ECJ1VB1H102K 50V 1000P 1
C4011 ECJ1VB1H102K 50V 1000P 1
C4012 F2A1E470B030 25V 47U 1
C4013 F2A1E470B030 25V 47U 1
C4014 F2A1H100B040 50V 10P 1
C4015 F2A1H100B040 50V 10P 1
C4016 F2A1E470B030 25V 47U 1
C4017 F2A1E470B030 25V 47U 1
C4018 ECJ2VC1H102J 50V 1000P 1
C4019 ECJ2VC1H102J 50V 1000P 1
C4020 F2A1C471B112 16V 470P 1
C4021 ECQV1H104JL3 50V 0.1U 1
C4022 ECJ1VF1C104Z 16V 0.1U 1
C4027 ECJ1VB1H103K 50V 0.01U 1
C4028 F1H1C104A090 16V 0.1U 1
C4901 F2A0J470A824 6.3V 47U 1
C4902 F1H1C104A090 16V 0.1U 1
C7301 F2A0J220A878 6.3V 22P 1
C7302 F2A1H4R7B033 50V 4.7U 1
C7304 F2A0J220A878 6.3V 22P 1
C7305 F2A1H4R7B033 50V 4.7U 1
C7306 F2A1H4R7B033 50V 4.7U 1
C7308 ECJ1VB1C473K 16V 0.047U 1
C7310 F2A0J470A824 6.3V 47U 1
C7311 ECJ1VB1H103K 50V 0.01U 1
C7312 F1H1C104A090 16V 0.1U 1
C7313 F2A1C100B099 16V 10P 1
15.2. Replacement Parts List
72
DMR-EZ28P / DMR-EZ28PC
