Panasonic DP-MB310EU - Service Function Table ( Fax Supported Models Only )

143
KX-MB2230EU/ KX-MB2270EU/ KX-MB2515EU/ KX-MB2545EU/ KX-MB2575EU/ DP-MB310EU
11.1.4. Service Function Table ( Fax supported models only )
Code Function Set Value Effective
Range
Default Remarks
501 Pause time set X 100msec 001~600 030 ----------
503 Dial speed select 1: 10pps
2: 20pps
1, 2 1 ----------
507 V34 transmission start speed 0: Disable
1: 33.6
2: 31.2
3: 28.8
4: 26.4
5: 24.0
6: 21.6
7: 19.2
8: 16.8
0~8 1 If the code 527 is set at 2, the code 507 and 508
work.
508 V34 reception start speed 0: Disable
1: 33.6
2: 31.2
3: 28.8
4: 26.4
5: 24.0
6: 21.6
7: 19.2
8: 16.8
0~8 1 If the code 527 is set at 2, the code 507 and 508
work.
514 Bell signal detect time X 100msec 1~9 3 ----------
520 CED frequency select 1: 2,100Hz
2: 1,100Hz
1, 2 1 See How To Output The Journal Report (P.224).
521 International mode select 1: ON
2: OFF
1, 2 1 See How To Output The Journal Report (P.224).
522 Auto standby select 1: ON
2: OFF
1, 2 1 The resolution reverts to the default when transmis-
sion is complete.
523 Receive equalizer select 1: 0km
2: 1.8km
3: 3.6km
4: 7.2km
1~4 1 Set RX equalizer to automatic mode.
524 Transmission equalizer select 1: 0km
2: 1.8km
3: 3.6km
4: 7.2km
1~4 1
527 V.8 function select 1: OFF
2: ON
1, 2 2
552 DTMF signal tone test 1: ON
2: OFF
1, 2 2 See Test Functions (P.136).
553 Monitor on FAX communication
select
1: OFF
2: Phase B
3: ALL
1~3 1 Sets whether to monitor the line signal with the
unit's speaker during FAX communication or not.
554 Modem test See Test Functions (P.136).
565 Irregular data set 1: Non-Delete
e
2: Delete
1,2 1 Sets whether delete Caller ID irregular data or not .
567 T0 timer X sec 001~255 052 Sets a higher value when the response from the
other party needs more time during automatic FAX
transmission.
570 BREAK% select 1: 61%
2: 67%
3: 63%
1, 2, 3 1 Sets the% break of pulse dialing according PBX.
573 Remote turn-on ring number set X number of
rings
00~99 10 Sets the number of rings before the unit starts to
operate TAM in the TEL mode.
574 Dial tone detect check 1: ON
2: OFF
1, 2 2 ----------
590 FAX auto redial time set X number of
times
00~99 05 Selects the number of redial times during FAX com-
munication (not including the first dial).
591 FAX auto redial line disconnection
time set
X sec 001~999 065 Sets the FAX redial interval during FAX communi-
cation.
592 CNG transmit select 1: OFF
2: ALL
3: AUTO
1~3 2 Lets you select the CNG output during FAX trans-
mission. ALL: CNG is output at phase A. AUTO:
CNG is output only when automatic dialing is per-
formed. OFF: CNG is not output at phase A. Refer
to Sometime There is a Transmit Problem
(P.217).
