Panasonic DVD-RV31 - Page 76

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
PP4301 K1KA22A00044 CONNECTOR(MALE)22P 1 [SPC]*14
PP4301 VJP4369E026B CONNECTOR(MALE)26P 1 K1KA26A00089
[SPC]*15
PP6001 K1KA06B00126 CONNECTOR(MALE)6P 1 [SPC]
PP6002 K1KA06B00126 CONNECTOR(MALE)6P 1 [SPC]
PP6003 K1KA10B00155 CONNECTOR(MALE)10P 1 [SPC]*15
PP6004 K1KA06B00126 CONNECTOR(MALE)6P 1 [SPC]
PR1161 VSF0015A025 IC PROTECTOR 1 D4FAR2500001
[SPC]
PR1171 VSF0015A10T IC PROTECTOR 1 B1ZAZ0000030
[SPC]
PR4911 VSF0015A10T IC PROTECTOR 1 B1ZAZ0000030
[SPC]*15
PS3201 K1KB18A00034 CONNECTOR(FEMALE)18
P
1 [SPC]*14
PS3201 VJS4222C022B CONNECTOR(FEMALE)22
P
1 K1KB22A00025
[SPC]*15
PS3801 VJS3042F019W CONNECTOR(FEMALE)19
P
1 K1KB19B00005
[SPC]
PS4201 VJS4222C022B CONNECTOR(FEMALE)22
P
1 K1KB22A00025
[SPC]*14
PS4201 VJS4222C026B CONNECTOR(FEMALE)26
P
1 K1KB26A00027
[SPC]*15
PS6001 K1KB06B00033 CONNECTOR(FEMALE)
6P
1 [SPC]
PS6002 K1KB06B00033 CONNECTOR(FEMALE)
6P
1 [SPC]
PS6003 K1KB10B00045 CONNECTOR(FEMALE)10
P
1 [SPC]*15
PS6004 K1KB06B00033 CONNECTOR(FEMALE)
6P
1 [SPC]
PS6201 VJS2961C010 CONNECTOR(FEMALE)10
P
1 K1KB10A00075
[SPC]
Q1021 2SC4908LF654 TRANSISTOR 1 B1BACT000012
[SPC]
Q1051 B3PBA0000104 PHOTO CUPLER 1 [SPC]
Q1052 2SD1996-STA TRANSISTOR 1 2SD19960SA
[SPC]
Q1115 B1DGDD000002 TRANSISTOR 1 [SPC]
Q3111 2SB1218A-R TRANSISTOR 1 2SB1218AR
[SPC]*15
Q3115 2SB1218A-R TRANSISTOR 1 2SB1218AR
[SPC]*15
Q3211 2SB1218A-R TRANSISTOR 1 2SB1218AR
[SPC]*15
Q3541 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Q3551 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Q3561 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Q3831 XN4402 TRANSISTOR 1 XN04402 [SPC]
Q3832 XN4401 TRANSISTOR 1 XN04401 [SPC]
Q3833 2SB710-R TRANSISTOR 1 2SB07100R
[SPC]*15
Q4302 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]
Q4309 2SD1328 TRANSISTOR 1 2SD132806
[SPC]*15
Q4310 2SD1328 TRANSISTOR 1 2SD132806
[SPC]*15
Q4311 2SD1328 TRANSISTOR 1 2SD132806
[SPC]*15
Q4410 2SD1328 TRANSISTOR 1 2SD132806
[SPC]
Q4411 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]
Q4412 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]
Q4413 2SD1328 TRANSISTOR 1 2SD132806
[SPC]*15
Q4413 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*14
Q4414 2SD1328 TRANSISTOR 1 2SD132806
[SPC]*15
Q4414 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*14
Q4415 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
Q4416 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Q4417 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Q4418 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Q4419 2SD1328 TRANSISTOR 1 2SD132806
[SPC]
Q4901 2SB709A-RSTX TRANSISTOR 1 2SB0709AHL
[SPC]*15
Q4911 2SB1434RSTA TRANSISTOR 1 2SB14340HA
[SPC]*15
Q4912 2SB1320A-RTA TRANSISTOR 1 2SB1320ARA
[SPC]*15
Q4913 2SD601A-RSTX TRANSISTOR 1 2SD0601AHL
[SPC]*15
Q5211 2SB1115-T TRANSISTOR 1 B1BDBF000004
[SPC]
Q5215 2SB1115-T TRANSISTOR 1 B1BDBF000004
[SPC]
Q6061 2SD1996-RSTA TRANSISTOR 1 2SD19960HA
[SPC]
Q6071 2SD1992A-R TRANSISTOR 1 [SPC]
QR1115 UN2213-TX TRANSISTOR 1 UNR221300L
[SPC]
QR3831 UN2217 TRANSISTOR 1 UNR2217
[SPC]*15
QR4301 UN2211 TRANSISTOR 1 UNR2211 [SPC]
QR4302 UN2211 TRANSISTOR 1 UNR2211 [SPC]
QR4304 UN2111 TRANSISTOR 1 UNR2111 [SPC]
QR4305 UN2211 TRANSISTOR 1 UNR2211
[SPC]*15
QR4306 UN2111 TRANSISTOR 1 UNR2111
[SPC]*15
QR5251 UN2121-TX TRANSISTOR 1 UNR212100L
[SPC]
QR6021 DTA123JK-T96 TRANSISTOR 1 B1GDCFEM0002
[SPC]*15
QR6022 DTA123JK-T96 TRANSISTOR 1 B1GDCFEM0002
[SPC]
QR6121 UN4219TA TRANSISTOR 1 UNR421900A
[SPC]*15
QR6122 UN4219TA TRANSISTOR 1 UNR421900A
[SPC]*15
QR6123 UN4114 TRANSISTOR 1 UNR4114
[SPC]*15
QR6301 UN5212-TX TRANSISTOR 1 UNR521200L
[SPC]
R1002 ERC12AGM334 330K 1 [SPC]
R1031 ERDS2FJ224 1/4W 220K 1 [SPC]
R1032 ERDS2FJ224 1/4W 220K 1 [SPC]
R1041 ERDS2TJ334 1/4W 330K 1 [SPC]
R1042 ERDS2TJ334 1/4W 330K 1 [SPC]
R1043 ERG2SJ680 2W 68 1 [SPC]
R1051 ERDS2TJ750 1/4W 75 1 [SPC]
R1052 ERDS2TJ2R2 1/4W 2.2 1 [SPC]
R1053 ERDS2TJ331 1/4W 330 1 [SPC]
R1054 ER0S2CKG6800 1/4W 680 1 [SPC]
R1101 ERJ3GEYJ750 1/16W 75 1 [SPC]
R1102 ERJ3GEYF122 1/16W 1.2K 1 [SPC]
R1103 ERJ3GEYF122 1/16W 1.2K 1 [SPC]
R1104 ERJ3GEYJ561 1/16W 560 1 [SPC]
R1105 ERJ6GEYJ271 1/10W 270 1 [SPC]
R1106 ERJ3GEYJ392 1/16W 3.9K 1 [SPC]
R1107 ERJ3GEYJ472 1/16W 4.7K 1 [SPC]
R1115 ERJ3GEYJ104 1/16W 100K 1 [SPC]
R1116 ERJ3GEYJ102 1/16W 1K 1 [SPC]
R1125 ERJ3GEYJ101 1/16W 100 1 D0GB101JA002
[SPC]
R1126 ERJ3GEYF122 1/16W 1.2K 1 [SPC]
R1127 ERJ3GEYF122 1/16W 1.2K 1 [SPC]
R1161 ERJ3GEYJ104 1/16W 100K 1 [SPC]
R1181 ERJ3GEYJ101 1/16W 100 1 D0GB101JA002
[SPC]
R2011 ERJ3GEYJ472 1/16W 4.7K 1 [SPC]
R2012 ERJ3GEYJ123 1/16W 12K 1 [SPC]
R2013 ERJ3RBD123 1/16W 12K 1 [SPC]
76
DVD-RV31 / DVD-RV41
