Panasonic DVD-S35E

6.8. Decoder PCB
1. Unscrew the screws.
2. Pull out the Mechanism Unit together with the Decoder PCB
Unit.
3. Unscrew the Screw bottom side of the Decoder PCB Unit.
6.9. Mechanism Unit
1. Remove the connectors between
Mechanism Unit and Decoder PCB Unit.
6.10. Terminal PCB
1. Unscrew the screw.
2. Remove the solders.
3. Remove the connector.
6.11. Front Panel PCB Unit
1. Unscrew the screws.
2. Remove the Chassis Ornament.
3. Remove the Front PCB Unit.
11
DVD-S35E / DVD-S35EB / DVD-S35EG / DVD-S31EG
