Panasonic DVD-S35E

9 ASSEMBLING AND
DISASSEMBLING THE
MECHANISM UNIT
9.1. Disassembly Procedure
9.2. Terminal PCB
1. Unscrew the screws.
2. Remove the solders.
3. Remove the connectors.
9.3. Clamp Plate Unit
1. Push the stopper with hand to slide the tabs and remove
the clamp plate unit.
21
DVD-S35E / DVD-S35EB / DVD-S35EG / DVD-S31EG
