17 REPLACEMENT PARTS
LIST
Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*ACHTUNG: Die Lasereinheit nicht zerlegen. Die
Lasereinheit darf nur gegen eine vom Hersteller
spezifizierte Einheit ausgetauscht werden.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
Ref.
No.
Part No. Part Name Pcs Remarks
Casing Parts
1 RYPD00011A-S Front Panel Assy 1 DVD-S35E-S
DVD-S35EB-S
DVD-S35EG-S
1 RYPD00011B-K Front Panel Assy 1 DVD-S35E-K
DVD-S35EB-K
DVD-S35EG-K
1 RYPD00012A-S Front Panel Assy 1 DVD-S31EG-S
1 RYPD00012B-K Front Panel Assy 1 DVD-S31EG-K
2 RKWD0003-R FL Window 1
3 VGB0560 Brand Badge Panas. 1
4 RYFD0001-S Tray Ornament Unit 1 DVD-S35E-S
DVD-S35EB-S
DVD-S35EG-S
DVD-S31EG-S
4 RYFD0001-K Tray Ornament Unit 1 DVD-S35E-K
DVD-S35EB-K
DVD-S35EG-K
DVD-S31EG-K
5 RMAD0003 Front support angle 1
6 XTBS26+10J Screw 8 Front PCB
Unit
7 RKMD0003-S Topcase 1 DVD-S35E-S
DVD-S35EB-S
DVD-S35EG-S
DVD-S31EG-S
7 RKMD0003-K Topcase 1 DVD-S35E-K
DVD-S35EB-K
DVD-S35EG-K
DVD-S31EG-K
8 VHD1094 Screw 2 DVD-S35E-S
DVD-S35EB-S
DVD-S35EG-S
DVD-S31EG-S
8 VHD1041 Screw 2 DVD-S35E-K
DVD-S35EB-K
DVD-S35EG-K
DVD-S31EG-K
9 XTBS3+8JFZ1 Screw 3 Topcase rear
10 RXKD0005 Chassis Unit 1
11 RGKD0008-K Chassis ornament 2
12 RKA0132-K Set Leg Unit 2
13 XTB3+6JFZ Screw 2 Set Leg Unit
14 RKA0137-K Rubber Cushion 2
Ref.
No.
Part No. Part Name Pcs Remarks
15 RGRD0003A-1A Rear Panel 1 DVD-S35E-S
DVD-S35E-K
DVD-S35EB-S
DVD-S35EB-K
DVD-S35EG-S
DVD-S35EG-K
15 RGRD0003A-1B Rear Panel 1 DVD-S31EG-S
DVD-S31EG-K
16 XTBS26+8J Screw 7 Rear Panel
17 RHD30102 Screw 4 Mecha
Chassis
18 REPD0006A Front PCB Unit 1 DVD-S35E-S
DVD-S35E-K
DVD-S35EB-S
DVD-S35EB-K
DVD-S35EG-S
DVD-S35EG-K
18 REPD0006B Front PCB Unit 1 DVD-S31EG-S
DVD-S31EG-K
19 XTBS3+8JFZ1 Screw 2 Power Unit
20 REXD0001 2PIN Cable 1
21 RHD30090 Screw 1 Decoder Unit
22 RHDC0002 Screw 1 Mecha-
Decoder
23 REYD0007 8PIN FFC 1
24 REPD0005A Decoder PCB 1 (RTL)
25 REPD0007A Power PCB 1 (RTL)
Mecha Chassis Unit
101 RXQ1016A Spindle Motor Assy 1
102 RMR1323-K Middle Chassis 1
103 RMS0712 Fixed Pin 2
106 REP3501A-C Terminal PCB 1 (RTL)
107 XTN2+6G Screw 1
108 RMG0545-A1 Floating Rubber 4
112 RDGC0499-J Traverse Gear (A) 1
113 RMC0415 Adjust Spring
Holder 1
3
116 RMEC0320 Adjust Spring 3
119 RMM0251 Traverse Drive Rack 1
120 RMSC0710 Guide Shaft (1) 1
121 RMSC0711 Guide Shaft (2) 1
122 RHD17045 Screw 2
123 VHD1224-C Screw 3
124 RDG0500 Traverse Gear (B) 1
125 RDG0501 Traverser Gear (C) 1
126 RMEC0319 Traverse Gear Spring 1
128 RGQ0280-K5 Tray 1
129 RXQ0727 Mecha Chassis Assy 1
129-1 XTW3+12S Screw 1
129-2 RSH1A049-U Open Switch 1 K0F111E00093
130 JSMC0048 Magnet 1
131 RMR1445-K Clamp Plate 1
132 RMR1447-X Magnet Holder 1
133 XWG6FFY Washer 1
134 RMR1446-X Clamper 1
138 RAF3023A Optical Pick-Up 1
139 RJB2309A Interface FPC 1
141 RMG0561-T Cushion Rubber 1
143 RQLCA0141 Laser Caution Label 1
146 RHD14108 Screw 1
147 REP3081A FG PCB 1 (RTL)
148 XTN2+6G SCREW 1
Packing Parts
A1 RPQFD0003 Accessory Box 1
A2 N2QAJB00069 Remote Control 1
A3 RJA0043-1C Powercord 1
DVD-S35E-S
DVD-S35E-K
DVD-S35EG-S
DVD-S35EG-K
A3 RJA0044-3C Powercord 1
DVD-S35EB-S
DVD-S35EB-K
A4 K2KA6CA00001 AV-Cord 1
58
DVD-S35E / DVD-S35EB / DVD-S35EG / DVD-S31EG
