Panasonic DVD-S35E

To Next Page

To Previous Page

Ref.

No.

Part No. Part Name Pcs Remarks

C2507 F1H1E104A030 25V 0.1F 1

C2508 F1H1E104A030 25V 0.1F 1

C2509 F1H1E104A030 25V 0.1F 1

C2511 F1H1E104A030 25V 0.1F 1

C2512 F1H1E104A030 25V 0.1F 1

C2521 F1H1E104A030 25V 0.1F 1

C2522 F1H1E104A030 25V 0.1F 1

C2531 F1H1E104A030 25V 0.1F 1

C3801 F1H1H103A220 50V 0.01F 1

C3802 ECUV1E103KBV 25V 0.01F 1

C3803 ECEA0JKA101B 6,3V 100pF 1

C3804 ECEA0JKA331Q 6,3V 330F 1

C3805 ECEA0JKA331Q 6,3V 330F 1

C3806 F1H1E104A030 25V 0.1F 1

C3808 F1H1E104A030 25V 0.1F 1

C3809 F1H1E104A030 25V 0.1F 1

C3810 F1H1E104A030 25V 0.1F 1

C3811 F1H1E104A030 25V 0.1F 1

C3812 ERJ3GEY0R00V 1/16W 0 1

C3822 F1H1E104A030 25V 0.1F 1

C3824 F1H1H101A736 50V 100pF 1

C3825 ECEA0JKA470B 6,3V 47F 1

C3826 ECEA1AKN470B 10V 47F 1

C3828 ECEA0JKA101B 6,3V 100pF 1

C3829 F1H1H101A736 50V 100pF 1

C3831 F2A1C220A234 16V 22F 1

C3832 F2A1C220A234 16V 22F 1

C3833 F2A1C220A234 16V 22F 1

C3834 ECEA1CKA220B 16V 22F 1

C3835 ECEA0JKA101B 6,3V 100pF 1

C3836 ECEA0JKA101B 6,3V 100pF 1

C3840 F2A0J102A247 6,3V 1000F 1

C3843 F2A0J102A247 6,3V 1000F 1

C4200 F2A1E221A205 25V 220F 1

C4201 F2A1C220A234 16V 22F 1

C4202 F2A1C220A234 16V 22F 1

C4203 F2A0J102A247 6,3V 1000F 1

C4204 F2A1E221A205 25V 220F 1

C4205 F1H1H102A009 50V 1000pF 1

C4206 F1H1H102A009 50V 1000pF 1

C4209 F3F1A1060002 10V 10F 1

C4210 F3F1A1060002 10V 10F 1

C4212 ECEA0JKA470B 6,3V 47F 1

C4213 ECEA0JKA470B 6,3V 47F 1

C4214 F1H1H103A220 50V 0.01F 1

C4215 ECEA1CKA470B 16V 47F 1

C4216 F2A1C220A234 16V 22F 1

C4217 ECEA0JKA470B 6,3V 47F 1

C4218 F1H1H103A220 50V 0.01F 1

C4221 F1H1H820A230 50V 82pF 1

C4222 F1H1H820A230 50V 82pF 1

C4226 F1H1H103A220 50V 0.01F 1

C4228 ECEA1AKA221Q 10V 220F 1

C4234 F1H1H222A219 50V 2200pF 1

C4235 ERJ3GEYJ681V 1/16W 680 1

C5101 ECEA0JKS470B 6,3V 47F 1

C5102 F1H1E104A030 25V 0.1F 1

C5103 F1H1E104A030 25V 0.1F 1

C5104 F1H1E104A030 25V 0.1F 1

C5120 ECEA1CKA470B 16V 47F 1

C5121 F1H1E104A030 25V 0.1F 1

C5122 ECST0JY475R 6,3V 4.7F 1

C5124 ECEA0JKA470B 6,3V 47F 1

C5131 F1H1E104A030 25V 0.1F 1

C5132 ECST0JY475R 6,3V 4.7F 1

C5134 ECEA0JKA470B 6,3V 47F 1

C5141 F1H1C104A071 16V 0.1F 1

C5142 F1H1C104A071 16V 0.1F 1

C6301 F1H1E104A030 25V 0.1F 1

C6302 F1H1E104A030 25V 0.1F 1

C6303 F1H1E104A030 25V 0.1F 1

C6304 F1H1E104A030 25V 0.1F 1

C6305 F1H1E104A030 25V 0.1F 1

Ref.

No.

Part No. Part Name Pcs Remarks

C6503 ECJ1VC1H050C 50V 5pF 1

C6505 ECJ1VC1H390J 50V 39pF 1

C6561 ECEA0JKA331Q 6,3V 330F 1

C6563 ECEA0JKA331Q 6,3V 330F 1

C6564 F1H1E104A030 25V 0.1F 1

C6566 F1H1E104A030 25V 0.1F 1

C6567 F1H1E104A030 25V 0.1F 1

D3801 MA2J11100L Chip Diode 1

D4201 MAZ4130NLF Diode 1

D4202 MA2J11100L Chip Diode 1

D4203 MAZ4051NHF Diode 1

D5111 MA2J72800L Diode 1

FP2501 K1MN08B00066 8 Pin

FFC Connector Female

FP5101 K1MN30B00025 30 Pin

FFC Connector Female

IC2002 C3ABQJ000001 IC 1

IC2003 C0EBE0000070 IC 1

IC2005 C0CBCBF00001 IC 1

IC2501 C0GBG0000033 IC 1

IC3001 MN2DS0002AP1 IC 1

IC3801 C9ZB00000282 IC 1

IC3802 C1AB00001731 IC 1

IC3802 MM1505XNRE IC 1

IC3803 C9ZB00000430 IC 1

IC3804 B3RAE0000021 IC 1

IC3804 K7AABA000001 IC 1

IC4200 C0FBBK000035 IC 1

IC4202 C0ABBB000125 IC 1

IC6301 C0JBAH000074 IC 1

IC6302 C0JBAH000074 IC 1

IC6303 C3FBMD000130 IC 1

IC6304 REPD0005A Decoder PCB Unit 1 must replace

PCB Unit

IC6561 C1DB00000582 IC 1

JK3801 K1FB121B0006 21 Pin Scart 1

JK3802 K2HA306B0070 6 Cinch Terminal 1

K2001 ERJ3GEY0R00V 1/16W 0 1

K2501 ERJ3GEY0R00V 1/16W 0 1

K2503 ERJ3GEY0R00V 1/16W 0 1

K3003 ERJ6GEY0R00Z 1/10W 0 1

K3801 ERJ3GEY0R00V 1/16W 0 1

K3803 ERJ3GEY0R00V 1/16W 0 1

K3804 ERJ3GEY0R00V 1/16W 0 1

K3806 ERJ3GEY0R00V 1/16W 0 1

L2001 G1C100KA0019 Chip Coil 1

L2002 G1C100KA0019 Chip Coil 1

L2003 G1C100KA0019 Chip Coil 1

L2005 G1C100KA0019 Chip Coil 1

L3801 G0C220JA0019 Choke Coil Axial 1

L3802 ERJ6GEY0R00Z Chip Resistor 1

L3803 ERJ6GEY0R00Z Chip Resistor 1

L3804 ERJ6GEY0R00Z Chip Resistor 1

L3807 G0C220JA0019 Choke Coil Axial 1

L3808 G0C471JA0003 COIL 1

L3809 G0C471JA0003 COIL 1

L4200 ERJ6GEY0R00V 1/16W 0 1

L4202 G0C220JA0019 Choke Coil Axial 1

L5121 G1C100KA0019 Chip Coil 1

L6561 G1C220K00013 Chip Coil 1

L6562 G1C220K00013 Chip Coil 1

LB2521 J0JBC0000015 Bead Core 1

LB2522 J0JBC0000015 Bead Core 1

LB3801 J0JBC0000015 Bead Core 1

LB3802 J0JBC0000015 Bead Core 1

LB3803 J0JBC0000015 Bead Core 1

LB3804 J0JBC0000015 Bead Core 1

LB4201 J0JCC0000062 Bead Core 1

LB4202 J0JCC0000062 Bead Core 1

LB5101 ERJ3GEY0R00V 1/16W 0 1

LB5102 J0JBC0000015 Bead Core 1

LB5103 ERJ3GEY0R00V 1/16W 0 1

LB5104 J0JHC0000045 Bead Core 1

LB5105 J0JCC0000119 Ferrite Core 1

DVD-S35E / DVD-S35EB / DVD-S35EG / DVD-S31EG

Main Page

Panasonic DVD-S35E - Page 60
