Panasonic DVD-S35E - Page 63

Ref.
No.
Part No. Part Name Pcs Remarks
C1015 F1BAF1020020 250V 1000pF 1
C1101 F2A1E121A078 25V 120F 1
C1102 F2A1E470A075 25V 47F 1
C1103 ECKR2H222KB5 500V 2200pF 1
C1104 F2A1E821A084 25V 820pF 1
C1105 F2A1E470A075 25V 47F 1
C1106 ECKR1H103ZF5 50V 0.01F 1
C1107 F2A1E821A084 25V 820pF 1
C1108 F2A1C5600011 16V 56F 1
C1109 VCF1JAH104K 63V 0,1F 1
C1111 F2A1V221A074 35V 220F 1
C1113 F2A1E331A081 25V 330F 1
C1114 F2A1V221A074 35V 220F 1
C1117 F2A1E121A078 25V 120F 1
C1118 ECQV1H104JL2 50V 0.1F 1
C1119 F2A1C5600011 16V 56F 1
C1151 F2A1C5600011 16V 56F 1
C1162 F2A0J1010063 6,3V 100F 1
C1170 ECQV1H104JL2 50V 0.1F 1
C1171 F2A0J1010063 6,3V 100F 1
C1172 ECQV1H104JL2 50V 0.1F 1
D1001 B0EAKV000015 Diode 1
D1002 B0EAKV000015 Diode 1
D1003 B0EAKV000015 Diode 1
D1004 B0EAKV000015 Diode 1
D1005 B0HADV000001 Diode 1
D1006 B0AAGP000004 Diode 1
D1007 ERZVA5V471 Surge Absorber 1
D1101 B0AAGP000004 Diode 1
D1102 B0EAMP000019 Diode 1
D1102 B0JAPG000019 Diode 1
D1103 B0HAMM000029 Diode 1
D1104 B0EAME000002 Diode 1
D1106 B0EALM000002 Diode Hand 1
D1106 B0JAML000007 Diode 1
D1107 B0AAGP000004 Diode 1
D1108 B0JAMG000010 Diode 1
D1153 B0EAKL000031 Diode 1
D1160 B0EAKV000015 Diode 1
D1170 MAZ40390HF Zener Diode 1
F1001 K5D162BL0007 Miniature Fuse 1
IC1001 C0DACZZ00005 IC 1
IC1102 C0DAEMZ00001 IC 1
IC1150 C0DAZHG00032 IC 1
IC1171 C0CAAYA00005 IC 1
L1001 ELF15N004A Line Filter 1
L1002 EXCELDR35V Bead Core 1
L1003 EXCELDR35V Bead Core 1
L1101 G0C221JA0019 Choke Coil Axial 1
L1102 G0A100H00010 Fixed Inductor 1
L1103 G0A100H00010 Fixed Inductor 1
P1001 K2AA2B000004 AC Inlet 1
P1103 K1KA02A00229 2P Connector Female 1
PP1101 K1KA19Z00001 16P Connector Male 1
PR1104 B1ZAZ0000034 IC 1
PR1105 B1ZAZ0000036 IC 1
PS1102 K1KB18B00017 18P Connector Female 1
Q1001 B3PAA0000012 Photo Coupler 1
Q1101 2SD21770RA Transistor 1
Q1102 2SB14170QA Transistor 1
Q1170 2SD1992ARA Transistor 1
Q1171 2SD19960SA Transistor 1
Q1172 2SD19960SA Transistor 1
Q1173 2SD1992ARA Transistor 1
QR1101 UNR421300A Transistor 1
R1001 ERC12UGK225C 2.2M 1
R1002 ERG2SJ683E 2W 68k 1
R1003 ERDS2TJ474T 1/4W 470k 1
R1004 ERDS2TJ474T 1/4W 470k 1
R1007 ERX12SJ1R0E 1/2W 1 1
R1008 ERDS2FJ105T 1/4W 1M 1
R1009 ERDS2FJ105T 1/4W 1M 1
R1102 ERG12SJ100E 1/2W 10 1
Ref.
No.
Part No. Part Name Pcs Remarks
R1104 ERDS2TJ471T 1/4W 470 1
R1106 ERG1SJ100E 1W 10 1
R1108 ERDS2TJ332T 1/4W 3.3k 1
R1109 ERDS2TJ102T 1/4W 1K 1
R1110 ERDS2TJ101T 1/2W 100 1
R1111 EROS2THF4321 1/4W 4.3k 1
R1112 ERDS2TJ202T 1/4W 2k 1
R1113 EROS2THF1201 1/4W 1.2k 1
R1115 ERDS2TJ104T 1/4W 100k 1
R1122 EROS2THF1182 1/4W 11,8k 1
R1150 ERDS2TJ331T 1/4W 330 1
R1151 ERDS1VJ391T 1/2W 390 1
R1152 ERDS2TJ151T 1/4W 150 1
R1153 ERDS2TJ222T 1/4W 2.2k 1
R1170 ERDS2TJ221T 1/4W 220 1
R1171 ERDS1VJ1R2T 1/2W 1.2 1
R1172 ERDS1VJ1R2T 1/2W 1.2 1
R1173 ERDS2TJ221T 1/4W 220 1
R1174 ERDS2TJ221T 1/4W 220 1
R1175 ERDS2TJ152T 1/4W 1.5k 1
R1176 ERDS2TJ102T 1/4W 1k 1
R1177 ERDS2TJ221T 1/4W 220 1
R1192 ERDS2TJ680T 1/4W 68 1
T1001 ETS33KH176BG Transformer 1
ZA1001 EYF52BC Fuse Holder 1
ZA1002 EYF52BC Fuse Holder 1
ZA1011 VMC1359 Earth Spring 1
ZA1101 K9ZZ00000424 Earth Terminal 1
ZA1102 K9ZZ00000424 Earth Terminal 1
Terminal PCB Unit
FP2601 8Pin
Connector Female
1
FP2602 4Pin Connector Male 1
C2601 F1E1H104A001 50V 0.1F 1
C2602 F1E1H104A001 50V 0.1F 1
SW2601 RSH1A04B-A Traverse Switch 1
63
DVD-S35E / DVD-S35EB / DVD-S35EG / DVD-S31EG
