26
7-3. Outdoor Unit PCB Setting
Fig. 7-4
(for single-phase outdoor unit PCB)
CN-A.ADD
CN-MODE
D303
(LED2)
D302
(LED1)
S003
CN-TERMINAL
S002
S004
CN-A.ADD
CN-MODE
D303
(LED2)
D302
(LED1)
S003
CN-TERMINAL
S002
S004
(for 3-phase outdoor unit PCB)
