Possible cause of malfunction
Alarm
message
Thermistor fault
Indoor thermistor
is either open or
damaged.
Indoor coil temp. sensor (E1) <<F01>>
Indoor coil temp. sensor (E2) <<F02>>
Indoor coil temp. sensor (E3) <<F03>>
Indoor suction air (room) temp.
sensor (TA)
<<F10>>
Indoor discharge air temp.
sensor (BL)
<<F11>>
Outdoor
thermistor is either
open or damaged.
Compressor No. 1 discharge
gas temp. sensor (TD)
F04
Outdoor No. 1 coil gas temp.
sensor (EXG1)
F06
Outdoor No. 1 coil liquid temp.
sensor (C1)
F07
Outdoor air temp. sensor (TO) F08
Compressor intake port
temperature sensor (TS)
F12
High pressure sensor failure F16
Low pressure sensor failure F17
EEPROM on indoor unit PCB failure F29
Protective device for compressor is activated
Protective device
for compressor
No. 1 is activated.
EEPROM on the outdoor unit
PCB is a failure.
F31
Overcurrent of power supply
current (CT) sensor
H01
PAM failure H02
Power supply current (CT)
sensor failure (Current is not
detected at time of compressor
ON.)
H03
Discharge gas temperature
of the comp. No. 1 is not
detected.
Temp. sensor is not seated at
the sensor holder.
H05
Low pressure switch is
activated.
H06
Low oil level. H07
Oil sensor fault.
(Disconnection,
etc)
Comp. No. 1 oil sensor
H08
Alarm messages displayed on system controller
Serial communication errors⁄
Mis-setting
Error in
transmitting serial
communication
signal
Indoor or main outdoor unit is
not operating correctly.
Mis-wiring of control wiring
between indoor unil, main
outdoor unit and system
controller.
C05
Error in
receiving serial
communication
signal
Indoor or main outdoor unit is
not operating correctly. Mis-
wiring of control wiring between
indoor unit, main outdoor unit
and system controller.
CN1 is not connected properly.
C06
Activation of
protective device
Protective device
of sub indoor unit
in group control is
activated.
When using wireless remote
controller or system controller,
in order to check the alarm
message in detail, connect
wired remote controller to
indoor unit temporarily.
P30
NOTE
1. Alarm messages in << >> do not affect other indoor unit
operations.
2. Alarm messages in < > sometimes affect other indoor unit
operations depending on the fault.
