Assembly
1
Place the controller on the seat so
that the controller cord passes over
the thigh massage section
( Do not trap the controller cord when installing armrests)
2
Check the "Right" and "Left" markings
on the underside of the armrest and the
hook catch part on the inside
3
Attach the right hand side armrest
to the main unit
①
Hold the part of the armrest on the right hand
side with both hands from the outside
②
Hook the inside hooks onto the hooks (blue) on the side of
the main body and lower the armrests along the main body
●
Make sure that the controller cord is not trapped.
4
Slide the armrests
back
●
Make sure that the hooks (blue)
on the side of the main unit are not
visible through the gap between the
main unit and the armrest.
If the hook (blue) is
visible, the armrest is
not attached correctly.
<Outside of armrest>
<Inner side of armrest>
●
Always raise the backrest. (EN11 steps 4 to 5)
If the backrest is collapsed, the armrest cannot be installed correctly.
●
Be careful not to get your fingers trapped.
Holding
area
Hook
(blue)
Hook catch part (inside)
Underneath the plastic part
Thigh Massage Section
×
Right hand side Left hand side
Hook catch part (inside)
EN12
To Next Page
