48 Installation Manual
Battery Connection & Charging Information
7. To read the battery status and state-of-charge (SOC) please refer to
the following diagram and table shown below.
SOC LED Indicator
SOC Display Switch
Status Indicator
Battery Status Display (Dual Color Type)
Battery SOC Display (Dual Color Type)
