Panasonic FP-X0 L40MR - Page 199

12-3
Power supply specifications
Item Specifications
Rated voltage 100 to 240 V AC
Voltage regulation range 85 to 264 V AC
Inrush current
L14: 35A or less (at 240 V AC, 25 C)
L30/L40/L60: 40A or less (at 240 V AC, 25 C)
Momentary power off time 10 ms (when using 100 V AC)
Frequency 50/60 Hz (47 to 63 Hz)
Leakage current 0.75 mA or less between input and protective earth terminals
Internal power supply part
Guaranteed life
20,000 hours (at 55 C)
Fuse Built-in (Cannot be replaced)
Insulation system Transformer insulation
Terminal screw M3
Service Power Supply for Input (Output) (For L30/L40/L60)
Item Specifications
Rated output voltage 24 V DC
Voltage regulation range 21.6 to 26.4 V DC
Rated output current 0.3 A
Overcurrent protection function
Note)
Available
Terminal screw M3
Note) This is a function to protect overcurrent temporarily. If a current load that is out of the
specifications is connected, it may lead to damages.
Unit’s current consumption table
Unit type
Current consumption of power supply
for Control unit
100 V AC 200 V AC
Control unit
AFP
X
-L14R 100 mA or less 70 mA or less
AFP
X
-L30R 330 mA or less 210 mA or less
AFP
X
-L40R 350 mA or less 220 mA or less
AFP
X
-L40MR 350 mA or less 220 mA o
r
less
AFP
X
-L60R 390 mA or less 250 mA or less
AFP
X
-L60MR 390 mA or less 250 mA or less
Expansion I/O unit
AFP
X
-E16R
N
o
t
e
1)
65 mA or less 40 mA or less
AFP
X
-E30R
N
o
t
e
2)
310 mA or less 210 mA or less
AFP
X
-E16T
N
o
t
e
1)
20 mA or less 10 mA or less
AFP
X
-E16P
N
o
t
e
1)
30 mA or less 15 mA or less
AFP
X
-E30T
N
o
t
e
2)
345 mA or less 220 mA or less
AFP
X
-E30P
N
o
t
e
2)
350 mA or less 225 mA or less
AFP
X
-E16X
N
o
t
e
1)
20 mA or less 10 mA or less
AFP
X
-E14YR
N
o
t
e
1)
75 mA or less 40 mA or less
Programmable display
GT02,GT02L
(5 VDC,RS232C type)
25 mA or less 15 mA or less
Note1) These current consumption indicate the increased amount of the current consumption of the ｃｃ
control unit.
Note2) The current consumption of E30 is the current consumption at the supply terminal of E30. The
current consumption of the control unit does not increase.
