Panasonic FP-X0 L40MR - Page 200

12.1.2 Performance Specifications
Item
Descriptions
L14
L30
L40
L60
No. of
contro-
llable
I/O
points
Control unit
14 points
DC input: 8,
Ry output: 4
Tr output: 2
30 points
DC input: 16,
Ry output: 10
Tr output: 4
40 points
DC input: 24,
Ry output: 12
Tr output: 4
60 points
DC input: 32,
Ry output: 24
Tr output: 4
When using E16R
expansion I/O units
- -
Max. 88 points
(Max. 3 units)
Max. 108 points
(Max. 3 units)
When using E30R
expansion I/O units
- -
Max. 130 points
(up to 3 units)
Max. 150 points
(up to 3 units)
Programming method/Control
method
Relay symbol/Cyclic operation
Program memory
Built-in Flash ROM (without backup battery)
Program capacity
2.5k steps
2.5k steps
8k steps
8k steps
No. of
instruction
Basic
114
High-level
230
Operation speed
From 0.08 µs/step (by basic instruction)
From 0.32 µs/step (by high-level
instruction) (MV instruction)
Up to 3k steps:
From 0.08 µs/step (by basic
instruction)
From 0.32 µs/step (by high-level
instruction) (MV instruction)
From 3k steps:
From 0.58 µs/step (by basic
instruction)
From 1.62 µs/step (by high-level
instruction) (MV instruction)
Base time 0.15 ms 0.18 ms
0.31 to 0.35 ms or
less
0.34 to 0.39 ms or
less
I/O refresh + base time
With E16: 0.4 ms x No. of units
With E30: 0.5 ms x No. of units
With expansion FP0 adapter: 1.4 ms + FP0 expansion unit refresh time
Note6)
Operation memory
Relay
External input (X)
Note1)
960 points (X0 to X59F)
1760 points (Y0 to Y109F)
External output (Y)
Note1)
960 points (X0 to X59F)
1760 points (Y0 to Y109F)
Internal relay (R)
1008 points (R0 to R62F)
4096 points (R0 to R255F)
Special internal relay (R)
224 points
224 points
Timer/Counter (T/C)
256 points
Note2)
(for initial setting, Timer: 250 points (T0
to T249), Counter: 6 points (C250 to
C255))
Timer: can count up to (in units of 1ms,
10ms, 100ms or 1s)× 32767.
Counter: Can count up to 1 to 32767.
1024 points
Note2)
(for initial setting, Timer: 1008 points
(T0 to T1007), Counter: 16 points
(C1008 to C1023))
Timer: can count up to (in units of 1ms,
10ms, 100ms or 1s)× 32767.
Counter: Can count up to 1 to 32767.
Link relay(L)
None
2048 points (L0 to L127F)
Memory area
Data register (DT)
2500 words (DT0 to DT2499)
8192 words (DT0 to DT8191)
Special data register
(DT)
420 words 420 words
Link data register (LD) None 256 word
Index register (I) 14 words (I0 to ID) 14 words (I0 to ID)
Differential points Unlimited points
Master control relay points
(MCR)
32 points 256 points
No. of labels (JP and LOOP)
100 points
256 points
No. of step laddars
128 stages
1000 stages
No. of subroutines
100 subroutines
500 subroutines
