Num-
ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
F329
P329
Floating-point type
data to 16-bit
integer con-
version
(rounding the first
decimal point down
to integer)
FIX
PFIX
S, D
Converts real number data specified
by (S+1, S) to the 16-bit integer data
with sign (rounding the first decimal
point down), and the converted data
is stored in “D”.
8
*1
F330
P330
Floating-point type
data to 32-bit
integer con-
version
(rounding the first
decimal point down
to integer)
DFIX
PDFIX
S, D
Converts real number data specified
by (S+1, S) to the 32-bit integer data
with sign (rounding the first decimal
point down), and the converted data
is stored in (D+1, D).
8 *1
F331
P331
Floating-point type
data to 16-bit
integer con-
version
(rounding the first
decimal point off to
integer)
ROFF
PROFF
S, D
Converts real number data specified
by (S+1, S) to the 16-bit integer data
with sign (rounding the first decimal
point off), and the converted data is
stored in “D”.
8 *1
F332
P332
Floating-point type
data to 32-bit
integer con-
version
(rounding the first
decimal point off to
integer)
DROFF
PDROFF
S, D
Converts real number data specified
by (S+1, S) to the 32-bit integer data
with sign (rounding the first decimal
point off), and the converted data is
stored in (D+1, D).
8 *1
F333
P333
Floating-point type
data round-
ding the
first decimal point
down
FINT
PFINT
S, D
The decimal part of the real number
data specified in (S+1, S) is rounded
down, and the result is stored in
(D+1, D).
8 *1
F334
P334
Floating-point type
data round-ding the
first decimal point
off
FRINT
PFRINT
S, D
The decimal part of the real number
data stored in (S+1, S) is rounded
off, and the result is stored in (D+1,
D).
8 *1
F335
P335
Floating-point type
data sign changes
F+/-
PF+/-
S, D
The real number data stored in (S+1,
S) is changed the sign, and the result
is stored in (D+1, D).
8 *1
F336
P336
Floating-point type
data absolute
FABS
PFABS
S, D
Takes the absolute value of real
number data specified by (S+1, S),
and the result (absolute value) is
stored in (D+1, D).
8
*1
F337
P337
Floating-point type
data degree
→
radian
RAD
PRAD
S, D
The data in degrees of an angle
specified in (S+1, S) is converted to
radians (real number data), and the
result is stored in (D+1, D).
8 *1
F338
P338
Floating-point type
data radian
→
degree
DEG
PDEG
S, D
The angle data in radians (real
number data) specified in (S+1, S) is
converted to angle data in degrees,
and the result is stored in (D+1, D).
8
*1
Floating-point type real number data processing instructions
F345
P345
Floating-point type
data compare
FCMP
PFCMP
S1, S2
(S1+1, S1)>(S2+1, S2)→ R900A: on
(S1+1, S1)=(S2+1, S2)→ R900B: on
(S1+1, S1)<(S2+1, S2)
→
R900C: on
10
F346
P346
Floating-point type
data band compare
FWIN
PFWIN
S1,
S2, S3
(S1+1, S1)>(S3+1, S3)→ R900A: on
(S2+1, S2)<or =(S1+1, S1)<or
=(S3+1, S3) → R900B: on
(S1+1, S1)<(S2+1, S2)
→
R900C: on
14
: Available, : Not available, : Not available partially
*1) This instruction is available for FP-e Ver.1.21 or later, and FP0 V2.1 or later.
