5.1.2 Installation and Removal
Attachment to DIN rail and removal from DIN rail
Can be simply attached to DIN rail.
Procedure of installation method
(1) Fit the upper hook of the unit onto the DIN rail.
(2) Without moving the upper hook, press on the lower hook to fit the
unit into position.
Procedure of removal method
(1) Insert a slotted screwdriver into the DIN rail attachment lever.
(2) Pull the attachment lever downwords.
(3) Lift up the unit and remove it from the rail.
