FP2 Serial Data Unit
Parts and Functions
2 − 6
2.1 Parts and Functions
Transmission speed and transmission format settings when shipped from factory
Transmission speed 9600bps Control signals CS and CD Invalid...... ...
Data length 8 bits End code C
R
.............. ..................
Parity check odd Start code Invalid............. .................
Stop bit 1 bit.................
Note
With regard to the transmission format, in addition to using the
transmission format setting switch (DIP switch), settings can also
be entered by setting the data from the ladder program in the
“Transmission format setting area” of the shared memory. See
section 3.2.2.
Items which can be set using the
transmission
format
settting
switch
Items which can be set in the shared
memory
transmission
format
settting
switch
(DIP switch)
memory
Transmission speed, Data length Transmission speed, Data length
Parity check, Stop bit
Control signals CS and CD
End code, Start code
