6.9 GT32
6.9.1 General Specifications (GT32)
Item
Specifications
GT32M
GT32T0
GT32T1
Rated voltage
24 V DC
Operating voltage range
21.6 to 26.4 V DC
Power consumption
10 W or less (410 mA or less)
12 W or less (500 mA or less)
Insulation method of
power supply part
Transformer insulation
Ambient temperature
0 to +50 C
Note1)
Ambient humidity
20 to 85% RH (at 25 C), non-condensing
Storage temperature
-20 to +60 C
Storage humidity
10 to 85% RH (at 25 C), non-condensing
Breakdown voltage
Note2)
Between [power supply terminals] and [case]
500 V AC for 1 minute, Cutoff current 10mA (at default setting)
Insulation resistance
Note2)
Between [power supply terminals] and [case]
100 M or more, 500 V DC, measured with megohmmeter (at default
setting)
Vibration resistance
10 to 55 Hz (1-minute cycle), Amplitude: 0.75 mm, 10 min on 3 axes
Shock resistance
98 m/s
2
, 4 times on 3 axes
EC Directive applicable
EN61131-2 (EMC Directive)
Noise immunity
1000 V [P-P] or more, Pulse width 50 ns, 1s between power supply
terminals (based on in-house measurements)
Note3)
Protective construction
IP65 (Initial value, evaluated by us)
Dustproof and drip-proof from front panel only (packing used on panel
contact surface)
Note4)
Weight
Approx. 500 g
Approx. 470 g
Approx. 480 g
Note1) When it is installed in a horizontal orientation (installed to make the liquid crystal face be topside),
the usable range is 0 to +40 C.
Note2) Not isolated between the USB port, COM port, Ethernet port (GT32T1 only) and the internal
digital circuit.
Note3) When using our exclusive cable.
Note4) When reattaching, replace waterproof packing.
