Panasonic GT02

To Next Page

To Previous Page

4-6

Connecting with 24 V DC type

Usable models

PLC

PLC communication cable

Programmable display

FP-X

FP

FP0/FP0R

FP-e

FP2/FP2SH

Mini-DIN 5-pin

loose-wire cable

AIGT8162

AIGT8165

AIGT8160

24 V DC

RS232C type

Connecting to the TOOL port
