37
VQT2D01
Perform the touch screen calibration if a different
object to the one touched is selected.
1 Select the menu. (l 29)
≥ Touch [ENTER].
2 Touch the [_] with the supplied
stylus pen and enter in
calibration.
≥ Touch the [_] in the order it is displayed.
(5 locations)
3 Touch [ENTER].
≥ Calibration cannot be performed when the LCD
monitor is turned 180o.
¬Change the mode to .
Rotate the LCD monitor towards the
lens side.
≥ The image is horizontally flipped as if you see
a mirror image. (However the image recorded
is the same as a normal recording.)
≥ Only some indications will appear on the
screen. When ° appears, return the direction
of the LCD monitor to normal position and
check the warning/alarm indication. (l 122)
Touch screen calibration
[SETUP] # [CALIBRATION] # [YES]
Recording Yourself
