24
VQT2W75
Basic
Recording/
Playback
3
Recording still pictures
≥ Open the lens cover before turning on the unit. (l 8)
1 Change the mode to .
2 Open the LCD monitor.
3 Press the button
halfway. (For auto focus
only)
4 Press the button fully.
Focus indication:
≥ If you set the Optical image stabilizer function (l 40) to (MODE1), then the image
stabilizer function will be more effective. ( (MEGA optical image stabilizer) will be
displayed when the button is pressed halfway.)
≥ In dark environments, the video light will turn on.
≥ Focus indication will change to registered focus icon when [FACE RECOG.] is set to [ON].
(l 53)
≥ It is recommended using a flash or tripod when recording still pictures in dark places
because the shutter speed becomes slow.
≥ The screen will become darker when the button is pressed halfway if the shutter speed
is 1/25 or slower.
≥ To print a picture, print using a PC or a printer.
A Focus indication
± (The white lamp flashes.):
Focusing
¥ (The green lamp lights up.):
When in focus
No mark:
When focusing is unsuccessful.
B Focus area (area inside brackets)
MEGA
