Panasonic KX-TDA15

2.3 Installing the Optional Service Cards
Getting Started 11
Slot Restrictions
The following table shows the slot restrictions. " " indicates that the slot supports the optional
service card.
Trunk Card Combinations
Trunk cards can be installed along with the pre-installed BRI2 card in any one of the following
combinations:
•BRI2 + BRI2
•BRI2 + BRI1
• BRI2 + LCOT2
• BRI2 + BRI1 + LCOT2
CAUTION
To protect the main board from static electricity, do not touch parts on the main board or on the
optional service cards. To discharge static electricity, touch ground or wear an earthing strap.
Card Slot Number
Type Max 0304050607091011
LCOT2 1
BRI2 1
BRI1 1
SIP-GW4 1
2IP-GW4 1
IP-EXT4 1
DLC8
1
*1
*1
Only one of either the DLC8 or SLC8 card can be installed.
SLC8
DPH4
1
*2
*2
Only one of either the DPH4 or DPH2 card can be installed.
DPH2
ECHO8 1
MSG2 2
SVM2 2
