11.1.4 Music on Hold
Description
Music can be played to any party on hold. The following audio sources are available:
a. Internal music source
b. External music source
c. Tone
Music Source Assignment
[KX-TDA100/KX-TDA200
/KX-TDA600]
BGM1, BGM2, and tone can be selected as Music on Hold through system programming. External music port
1 is assigned to BGM 1. It is possible to select whether external music port 2, internal audio source 1, or internal
audio source 2 is assigned to BGM2.
Having two external music ports, for example, allows the use of the BGM feature (® 2.1.1 BGM (Background
Music)), while assigning a separate external music source (e.g., company message, advertisement) to Music
on Hold.
[BGM Number and the Music Source]
BGM No. Available Audio Sources
1
2
External music port 1
External music port 2/Internal audio source 1 or 2
Separate music sources can be assigned for the Music on Hold and the BGM features.
[KX-TDA50]
Only one external music port is available. If BGM is selected, it is possible to select whether external music
port, internal music port 1, or internal music port 2 is assigned to BGM.
Conditions
• Hardware Requirement: User-supplied audio device (CD player, radio, etc.) when an external music
source is assigned.
• Volume Control
It is possible to change the volume of an internal and/or external music source.
• Each tenant can select a music source to use for Music on Hold. The type of call determines which
tenant’s music source is used, as follows:
Type Music Source
Incoming Intercom Calls/Outgoing
Calls
Selected based on the tenant setting to which the
extension user belongs.
Incoming CO Line Calls Selected based on the tenant setting of the distribution
method (DIL/DID).
Installation Manual References
KX-TDA50
2.10.1 Connection of Peripherals
Document Version 2008-11 Feature Manual 191
