2.7 Information about the Extension Cards
142 Installation Manual
2.7.3 DLC8 Card (KX-TDA0171)
Function
8-port digital extension card for DPTs, DSS consoles, and PT-interface CSs.
Accessories and User-supplied Items
Accessories (included): Screws × 2, Ferrite core × 1
User-supplied (not included): Amphenol connector
Notes
• Attach the included ferrite core to the cable. Refer to "2.2.14 Attaching a Ferrite Core".
• To connect the Amphenol connector, refer to "2.2.15 Fastening Amphenol Connector".
LED
Amphenol
To extensions
