2.10 Connection of 2.4 GHz Portable Stations
2.10.1 Overview
The following equipment is required to connect the wireless system:
CS: Cell Station (KX-TDA0142/KX-T0141)
KX-TDA0142 Using a CSIF Card
This unit determines the area covered by the wireless system. Up to 3 calls can be made at the same
time through each CS.
• CSIF4 (KX-TDA0143)
One CSIF4 card supports up to 4 Cell Stations.
• CSIF8 (KX-TDA0144)
One CSIF8 card supports up to 8 Cell Stations.
KX-T0141 Using a DHLC/DLC Card
This unit determines the area covered by the wireless system. Up to 2 calls can be made at the same
time through each CS.
PS: 2.4 GHz Portable Station (KX-TD7680/KX-TD7690)
The Hybrid IP-PBX can support up to 256 PSs. If an EMEC card is installed in the Hybrid IP-PBX, up to 512
PSs can be supported. For more details about the PS, refer to the PS Operating Instructions.
CAUTION
• The CS should be kept free of dust, moisture, high temperature (more than 40 °C [104 °F]), low
temperature (less than 0 °C [32 °F]), and vibration, and should not be exposed to direct sunlight.
• The CS should not be placed outdoors (use indoors).
• The CS should not be placed near high-voltage equipment.
• The CS should not be placed on a metal object.
• Systems using 2.4 GHz ISM (Industrial, Scientific and Medical) band may interfere with the KX-
TDA wireless system. Examples of such systems are cordless telephones, wireless LAN, Home
RF, microwave ovens and other ISM devices. These systems may cause minor noise.
• Keeping some distance between the equipment listed below may prevent interference. (The
distance may vary depending on the environment.)
Equipment Distance
CS and office equipment such as a computer, telex, fax
machine, etc.
More than 2 m (6 ft 7 in)
CS and PS More than 1 m (3 ft 3 in)
Each PS More than 0.5 m (1 ft 8 in)
Hybrid IP-PBX and CS More than 2 m (6 ft 7 in)
CS and CS More than 15 m (49 ft)
