2.1 Opening/Closing the Front Cover
8 Getting Started for Virtual IP Cards
2.1 Opening/Closing the Front Cover
Opening the Front Cover
1. Insert a flathead screwdriver into the opening (on the left of the screw cover) and unlatch the screw
cover. Turn the screw anticlockwise to loosen.
2. Slide the front cover to the right until it stops, then lift the front cover.
Closing the Front Cover
1. Hook the front cover onto the shelf (line up the protrusions on the cover with the receptacles on the
shelf), then slide the front cover to the left until it locks.
2. Turn the screw clockwise to tighten, then secure the screw cover.
