23.9. REPLACEMENT PARTS LIST
(KX-TE82460X)
Note:
1. RTL (Retention Time Limited)
The marking (RTL) indicates that the Retention Time is
limited for this item.
After the discontinuation of this assembly in production, the
item will continue to be available for a specific period of
time. The retention period of availability depends on the
type of assembly and the laws governing parts and product
retention. At the end of this period, the assembly will no
longer be available.
2. Important safety notice
Components identified by the
mark indicates special
characteristics important for safety. When replacing any of
these components, only use specified manufacture´s parts.
3. The S mark means the part is one of some identical parts.
For that reason, it may be different from the installed part.
4. ISO code (Example: ABS-94HB) of the remarks column
shows quality of the material and a flame resisting grade
about plastics.
5. RESISTORS & CAPACITORS
Unless otherwise specified;
All resistors are in ohms (Ω), k=1000Ω, M=1000kΩ
All capacitors are in MICRO FARADS (µF), p=µ(µF)
*Type & Wattage of Resistor
23.9.1. ACCESSORIES AND PACKING
MATERIALS
Ref.
No.
Part No. Part Name & Description Remarks
A1 PQJS1T30Z CONNECTOR
A2 PSJA1068Z CORD
A3 XYN3+F12FN SCREW
P1 PSPP1068Z PROTECTION COVER
P2 PSZKTE82460X GIFT BOX
P3 XZB05X08A03 PROTECTION COVER
23.9.2. MAIN BOARD PARTS
Ref.
No.
Part No. Part Name & Description Remarks
(ICS)
IC1A C0ABBB000179 IC
IC1C C0ABBB000179 IC
IC2A C0ABBB000179 IC
IC2C C0ABBB000179 IC
IC5 PSVICD4066BS IC S
IC6 C0JBAZ001852 IC
IC7 PSVISNLV273A IC S
IC8 PSVISNLV273A IC S
IC9 PSVITCVT138T IC S
IC10 C0JBAE000253 IC
IC11 C0JBAZ002268 IC
(TRANSISTORS)
Q1A UN5113 TRANSISTOR(SI) S
Q1C UN5113 TRANSISTOR(SI) S
Q2A UN5213 TRANSISTOR(SI) S
Q2C UN5213 TRANSISTOR(SI) S
Q3A PQVTDTC124EU TRANSISTOR(SI) S
Q3C PQVTDTC124EU TRANSISTOR(SI) S
Q7A UN521DTX TRANSISTOR(SI) S
Q7C UN521DTX TRANSISTOR(SI) S
Q8A PQVTDTC143E TRANSISTOR(SI) S
Q8C PQVTDTC143E TRANSISTOR(SI) S
U6A B1GFAFNN0001 TRANSISTOR(SI)
U6C B1GFAFNN0001 TRANSISTOR(SI)
(DIODES)
D2A MA8068M DIODE(SI) S
D2C MA8068M DIODE(SI) S
D3A MA110 DIODE(SI) S
D3C MA110 DIODE(SI) S
D4A MA110 DIODE(SI) S
D4C MA110 DIODE(SI) S
D5A MA110 DIODE(SI) S
D5C MA110 DIODE(SI) S
(CONNECTORS)
CN1 PSJS30P32Z CONNECTOR, 30P
CN2 K4AC04B00006 CONNECTOR, 4P
(COMPONENTS PARTS)
RA1 D1H82204A024 RESISTOR ARRAY, 22
RA2 D1H82204A024 RESISTOR ARRAY, 22
RA3 D1H82214A024 RESISTOR ARRAY, 220
RA4 D1H81034A024 RESISTOR ARRAY, 10K
(COILS)
L1A PQLE106 COIL S
L1C PQLE106 COIL S
L2A PQLE106 COIL S
L2C PQLE106 COIL S
(JACK)
CN3 K2LB104B0055 JACK, TEL
(TRANSFORMERS)
T1A PSLT8D7A TRANSFORMER S
T1C PSLT8D7A TRANSFORMER S
(RELAYS)
RL2A K6B1AGA00198 RELAY
RL2C K6B1AGA00198 RELAY
(VARISTORS)
ZNR1A D4EAB390A005 VARISTOR S
ZNR1C D4EAB390A005 VARISTOR S
ZNR2 D4EAB390A005 VARISTOR S
(CAPACITORS)
C4A ECUV1C333KBV 0.033
C4C ECUV1C333KBV 0.033
C5A F2G1C4700017 47
C5C F2G1C4700017 47
C6A ECUV1E104KBV 0.1
C6C ECUV1E104KBV 0.1
C7A ECUV1H331JCV 330P S
C7C ECUV1H331JCV 330P S
C8A F2G1H1R00013 1
C8C F2G1H1R00013 1
C9A F2G1C4R70002 4.7
101
KX-TEA308CE
