Panasonic KX-TEA308CE

Ref.
No.
Part No. Part Name & Description Remarks
D35 MA8056 DIODE(SI)
D50 PFVDERA2210 DIODE(SI) S
D101 PFVDYG911S2 DIODE(SI) S
D104 PSVDHZ30P DIODE(SI) S
D201 PSVDCB83304 DIODE(SI) S
D301 PSVDCB83304 DIODE(SI) S
D302 PSVDEC21QS04 DIODE(SI) S
D501 PSVDERA1506 DIODE(SI) S
D502 PSVDYG811S6R DIODE(SI) S
D504 MA8220 DIODE(SI)
D505 MA8200 DIODE(SI)
D506 PSVDERA1506 DIODE(SI) S
D507 1SS355 DIODE(SI) S
D508 1SS355 DIODE(SI) S
D509 1SS355 DIODE(SI) S
D510 MA8200 DIODE(SI)
(CONNECTORS)
CN1 PQJP2D98Z CONNECTOR S
CN101 B2B-EH-A CONNECTOR
CN301 B7B-PH-K-S CONNECTOR
CN501 B2P-VH CONNECTOR
(COILS)
BEA1 BLM31PG330 COIL
BEA11 PSLEBL02RN1 COIL S
BEA102 BLM41PG750 COIL
L1 0R6A273F20A COIL
L201 SBC9151 COIL S
L301 SBC9560 COIL S
(FUSES)
F1 PSBA382250A FUSE S
F501 PSBA382400A FUSE S
(TRANSFORMERS)
T1 PSLT89D1 TRANSFORMER S
(THERMISTOR)
NTC1 PSRTNTPA74R0 THERMISTOR S
(PHOTO ELECTRIC TRANSDUCERS)
PC1 PSVIPS2581 PHOTO COUPER S
(RELAY)
RL501 PSSLALD124 RELAY S
(VARISTOR)
Z1 PSRZC471D10A VARISTOR S
(CAPACITORS)
C1 PSCQELE224 0.22 S
C5 PSCEA450VB68 68 S
C8 DEA1X3D221 220P
C9 GRM39B222J50 0.0022
C12 GRM39B222J50 0.0022
C16 GRM40X224K50 0.22 S
C17 DE1E3KX472M 0.0047
C19 GRM39B104K50 0.1
C20 PSCEA35ZL56 56 S
C21 GRM39B104K50 0.1
C35 GRM39B105K63 1 S
C50 DEHR33A102K 0.001
C61 PSCQELE104 0.1 S
C62 PSCQELE104 0.1 S
C63 PFKD2E3KH102 0.001 S
C64 PFKD2E3KH102 0.001 S
C101 PSCEA35ZL330 33P S
C110 GRM39B104K50 0.1
C201 PSCEA25VB220 22P S
C204 GRM40B104K50 0.1
C301 PSCEA16ZL330 33P S
C302 PSCEA35Y1000 0.001 S
C303 GRM39CH221J5 220P
C306 GRM40B104K50 0.1
C501 GRM39B332J50 0.033
(RESISTORS)
BEA501 PQ4R18XJ000 0 S
J2 PQ4R10XJ000 0 S
J3 PQ4R10XJ000 0 S
J4 PQ4R10XJ000 0 S
R4 PQ4R10XJ682 6.8K S
Ref.
No.
Part No. Part Name & Description Remarks
R5 PQ4R10XJ682 6.8K S
R6 ERJ6GEYF101 100
R7 PQ4R10XJ100 10 S
R8 PQ4R10XJ561 560 S
R10 PQ4R10XJ472 4.7K S
R11 PQ4R18XJ000 0 S
R30 ERX2SJR56 0.56
R31 ERX2SJR47 0.47
R35 ERJ3GEYJ105 1M
R51 ERG2SJ104 100K
R52 RK73B2ATD274 270K S
R53 RK73B2ATD304 300K S
R54 RK73B2ATD304 300K S
R55 MCR100JZH331 330K S
R71 ERJ8GEYF274 270K
R72 ERJ8GEYF274 270K
R73 ERJ8GEYF274 270K
R110 PQ4R18XJ102 1K S
R111 ERJ3GEYJ102 1K
R112 ERJ3GEYJ472 4.7K
R113 ERJ3GEYJ332 3.3K
R114 ERJ3GEYJ272 2.7K
R115 ERJ3GEYJ303 30K
R201 ERJ3GEYJ223 22K
R202 EROS2THF2401 2.4K
R203 ERJ3GEYJ222 2.2K
R250 ERJ3GEY0R00 0
R301 ERJ3GEYJ152 1.5K
R302 ERJ3GEYJ102 1K
R308 ERJ3GEYJ151 150
R350 ERJ3GEY0R00 0
R501 RF16CT26A101 100
R502 ERJ3GEYJ561 560
R503 ERJ3GEYJ222 2.2K
R504 ERJ3GEYJ103 10K
R505 PQ4R10XJ472 4.7K S
R506 ERJ3GEYJ472 4.7K
R507 PQ4R18XJ472 4.7K S
R508 ERJ8GEYJ270 27
R509 ERJ8GEYJ270 27
R510 ERJ8GEYJ270 27
R511 ERJ8GEYJ270 27
R512 ERJ8GEYJ270 27
R513 ERJ8GEYJ270 27
R514 ERJ3GEYJ471 470
R515 ERJ3GEYJ102 1K
R516 PQ4R18XJ472 4.7K S
R517 ERJ3GEYJ471 470
R518 ERJ3GEYJ561 560
R519 PQ4R18XJ472 4.7K S
R520 PQ4R18XJ472 4.7K S
R521 ERJ8GEYJ270 27
19.6. FIXTURES AND TOOLS
Ref.
No.
Part No. Part Name & Description Remarks
EC1 PSZZTEA308BX EXTENSION CORD
Note: The Extension Cords are useful for servicing. (They
make servicing easy.)
62
KX-TEA308CE
