Panasonic KX-TEA308CE

Ref.
No.
Part No. Part Name & Description Remarks
R15C ERJ3GEYJ101 100
R16A ERJ3GEY0R00 0
R16B ERJ3GEY0R00 0
R16C ERJ3GEY0R00 0
R17A ERJ3GEYF122 1.2K S
R17B ERJ3GEYF122 1.2K S
R17C ERJ3GEYF122 1.2K S
R18A ERJ3GEYJ103 10K
R18B ERJ3GEYJ103 10K
R18C ERJ3GEYJ103 10K
R20A ERJ3GEYF122 1.2K S
R20B ERJ3GEYF122 1.2K S
R20C ERJ3GEYF122 1.2K S
R21A ERJ3GEY0R00 0
R21B ERJ3GEY0R00 0
R21C ERJ3GEY0R00 0
R22A ERJ3EKF5600 560
R22B ERJ3EKF5600 560
R22C ERJ3EKF5600 560
R23A ERJ3EKF1001 1K
R23B ERJ3EKF1001 1K
R23C ERJ3EKF1001 1K
R24A ERJ3EKF1003 100K
R24B ERJ3EKF1003 100K
R24C ERJ3EKF1003 100K
R25A ERJ3EKF1003 100K
R25B ERJ3EKF1003 100K
R25C ERJ3EKF1003 100K
R26A ERJ3GEYJ304 300K
R26B ERJ3GEYJ304 300K
R26C ERJ3GEYJ304 300K
R27A ERJ3GEYJ304 300K
R27B ERJ3GEYJ304 300K
R27C ERJ3GEYJ304 300K
R28A ERJ3GEYJ304 300K
R28B ERJ3GEYJ304 300K
R28C ERJ3GEYJ304 300K
R29A ERJ3GEYJ103 10K
R29B ERJ3GEYJ103 10K
R29C ERJ3GEYJ103 10K
R30A ERJ3GEYJ103 10K
R30B ERJ3GEYJ103 10K
R30C ERJ3GEYJ103 10K
R31A ERJ3GEYJ304 300K
R31B ERJ3GEYJ304 300K
R31C ERJ3GEYJ304 300K
R34A ERJ3EKF1003 100K
R34B ERJ3EKF1003 100K
R34C ERJ3EKF1003 100K
R35A ERJ3EKF1003 100K
R35B ERJ3EKF1003 100K
R35C ERJ3EKF1003 100K
R37A ERJ3GEYJ103 10K
R37B ERJ3GEYJ103 10K
R37C ERJ3GEYJ103 10K
R38A ERJ3GEY0R00 0
R38B ERJ3GEY0R00 0
R38C ERJ3GEY0R00 0
R39A ERJ3GEYF122 1.2K S
R39B ERJ3GEYF122 1.2K S
R39C ERJ3GEYF122 1.2K S
R40A ERJ3GEYF122 1.2K S
R40B ERJ3GEYF122 1.2K S
R40C ERJ3GEYF122 1.2K S
R41A ERJ3GEYJ151 150
R41B ERJ3GEYJ151 150
R41C ERJ3GEYJ151 150
R42A ERJ3GEYF122 1.2K S
R42B ERJ3GEYF122 1.2K S
R42C ERJ3GEYF122 1.2K S
R43A ERJ3GEY0R00 0
R43B ERJ3GEY0R00 0
R43C ERJ3GEY0R00 0
Ref.
No.
Part No. Part Name & Description Remarks
R45A ERJ3GEY0R00 0
R45B ERJ3GEY0R00 0
R45C ERJ3GEY0R00 0
R46A ERJ3GEYF122 1.2K S
R46B ERJ3GEYF122 1.2K S
R46C ERJ3GEYF122 1.2K S
R47A ERJ3GEYJ473 47K
R47B ERJ3GEYJ473 47K
R47C ERJ3GEYJ473 47K
R49A ERJ3GEYJ473 47K
R49B ERJ3GEYJ473 47K
R49C ERJ3GEYJ473 47K
R50A ERJ3GEYJ473 47K
R50B ERJ3GEYJ473 47K
R50C ERJ3GEYJ473 47K
R51A ERJ3GEYJ104 100K
R51B ERJ3GEYJ104 100K
R51C ERJ3GEYJ104 100K
R52A ERJ3GEYJ272 2.7K
R52B ERJ3GEYJ272 2.7K
R52C ERJ3GEYJ272 2.7K
R54A ERJ3GEYJ684 680K
R54B ERJ3GEYJ684 680K
R54C ERJ3GEYJ684 680K
R55A ERJ3GEYJ684 680K
R55B ERJ3GEYJ684 680K
R55C ERJ3GEYJ684 680K
R56A ERJ3GEYJ683 68K
R56B ERJ3GEYJ683 68K
R56C ERJ3GEYJ683 68K
R57A ERJ3GEYJ683 68K
R57B ERJ3GEYJ683 68K
R57C ERJ3GEYJ683 68K
R100 ERJ3GEYJ471 470
R101 ERJ3GEYJ683 68K
R102 ERJ3GEYJ473 47K
R103 ERJ3GEYJ223 22K
R104 ERJ3GEYJ104 100K
R105 ERJ3GEYJ393 39K
R106 ERJ3GEYJ103 10K
R107 ERJ3GEYJ223 22K
R108 ERJ1WYJ102 1K S
R109 ERJ3GEYJ104 100K
R719 ERJ3GEYJ271 270
19.5. POWER SUPPLY BOARD
PARTS
Ref.
No.
Part No. Part Name & Description Remarks
PCB3 PSLP1386Z POWER SUPPLY BOARD ASS´Y
(RTL)
(ICS)
IC1 PFVIFA5518N IC S
IC101 PSVITA76431S IC S
IC201 PSVIPQ1CG21H IC S
IC301 PSVIPQ1CG21H IC S
(TRANSISTORS)
Q1 2SK2843 TRANSISTOR(SI)
Q501 2SC4097 TRANSISTOR(SI) S
Q502 2SA1576A TRANSISTOR(SI)
Q503 2SD2012 TRANSISTOR(SI)
Q504 2SA1576A TRANSISTOR(SI)
(DIODES)
D3 PSVDERA2206 DIODE(SI) S
D4 1SS133 DIODE(SI)
D10 PSVDERA1506 DIODE(SI) S
D11 PSVDERA1506 DIODE(SI) S
D12 PSVDERA1506 DIODE(SI) S
D13 PSVDERA1506 DIODE(SI) S
D15 MA8330 DIODE(SI)
D16 MA8330 DIODE(SI)
61
KX-TEA308CE
