8 DISASSEMBLY INSTRUCTIONS
8.1. DISASSEMBLY INSTRUCTION
1. Pull the slide button (arrow 1) to the right and, holding it, slide the
cable cover upwards (arrow 2).
2. Then turn the cable cover slightly to remove it.
3. Remove the three screws (A).
4. Holding the protrusions on both sides of the front cover, swing the
cover open.
5. Holding the front cover open at about a 45° angle, remove the front
cover by pushing it in the direction of the arrow as shown on the right.
13
KX-TEA308CE
