34
DVQX2448 (ENG)
2. Getting Started
Extending/retracting the lens
<when the interchangeable lens (H-FS12032) is
attached>
How to Extend the Lens
Rotate the zoom ring in the direction
of arrow
from position (the lens
is retracted) to position
<12 mm to
32 mm> to extend the lens.
• When the lens barrel is retracted, images
cannot be recorded.
The lens is retracted
How to Retract the Lens
Rotate the zoom ring in the direction
of arrow
from position <12 mm to
32 mm> to position
to retract the lens.
• The zoom ring will seem to click into the
12 mm position, but continue to rotate the lens
until it reaches position
.
• When you are not recording images, we
recommend that you retract the lens.
The lens is extended
To Next Page
