Panasonic LUMIX DC-TZ95D User Manual

40
Basics
Basic Operation
■
[ ] Monitor style display layout (Example of monitor style display)
With information Without information
With information
+
level gauge
Without information
+
level gauge
50
p
50
p
Turned off
●
With [Fn Button Set] in the [Custom] ([Operation]) menu, you can assign [LVF/Monitor Disp. Style]
to a function button. Each time you press the assigned function button, the display style of the
monitor or viewfinder ([
]/[ ]), whichever is currently in use, will change.
■
Using the level gauge
The yellow line indicates the current angle. Correct the angle of the camera so that it
matches the white line.
Tilting up or down
• In this case, it is facing upward.
Tilting left or right
• In this case, the right side has
dropped.
• When the camera is tilted very little or not at all, the level gauge will turn green.
●
Even when angle is corrected, there may be an error of about ±1 degree.
●
The level gauge may not be displayed correctly or the direction detect function may not operate
correctly if the pictures are taken with the camera pointing sharply up or down.

Panasonic LUMIX DC-TZ95D Specifications

General

Sensor Size	1/2.3-inch
Lens	LEICA DC VARIO-ELMAR
Optical Zoom	30x
Digital Zoom	4x
Maximum Aperture	f/3.3 - 6.4
LCD Monitor	3.0-inch
Connectivity	Wi-Fi, Bluetooth
Sensor	MOS Sensor
Focal Length	4.3 - 129mm (35 mm equivalent: 24-720 mm)
Image Stabilization	5-axis Hybrid O.I.S. +
ISO Range	80 - 3200
ISO Sensitivity	Auto, 80, 100, 200, 400, 800, 1600, 3200, 6400
Shutter Speed	4 - 1/2000 sec (Mechanical Shutter)
Display	3.0-inch TFT Screen LCD Display
LCD Screen Resolution	1, 040k dots
Viewfinder	0.21-inch Live View Finder
Video Recording	[4K] 3840 x 2160 at 30p/ 25p/ 24p
Battery	Li-ion Battery Pack
Battery Life	Approx. 380 images (rear monitor)
Weight	Approx. 328 g (with battery and SD memory card)
