Before Use
21 Focus mode dial (P40, 44, 69, 72)
22 Flash open lever (P58)
23 Drive mode lever
Single (P44):
Burst (P64):
Auto bracket (P66):
Self-timer (P68):
24 Shutter button (P40)
25 Focus distance reference mark (P73)
26 Hot shoe (P128)
27 Mode dial (P38)
28 Status indicator (P40)
29 [Q.MENU] button (P29)
30 [FILM MODE] button (P81)
31 [REMOTE] socket (P131)
32 Strap eyelet (P17)
•
Be sure to attach the strap when using the
camera to ensure that you will not drop it.
33 [HDMI] socket (P125, 126)
34 [DIGITAL/V.OUT] socket (P118, 120, 124)
35 Card door (P23)
36 DC cable cover (P132)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or
Press 4
33
32
31
34
36
35
