Before Use
About the Lens
This unit can use the dedicated lenses compatible with the Micro Four Thirds System lens
mount specification (Micro Four Thirds mount) such as the lens included in DMC-G1K.
Select a lens that matches the scene being recorded and your use of the pictures.
If you use a lens other than a dedicated interchangeable lens, auto focus cannot be
activated and accurate metering is not possible. Also, some functions will not work.
∫ “Micro Four Thirds Mount”
This is the lens mount standard for the
“Micro Four Thirds System”.
This was newly developed as
interchangeable lens dedicated for digital
cameras.
∫ When using lenses other than the lens included in DMC-G1K
•
Depending on the type of lens, you may not be able to use some functions such as the direction
detection function (P36), [STABILIZER] (P100), Quick AF (P106) and Continuous AF (P106).
• The available flash range etc. differs depending on the aperture value of the lens you are using.
• Take some test pictures with the lens you are using.
• Lens with the Four Thirds™ mount
specification can be used by using the mount
adaptor (DMW-MA1; optional). However,
[AFC] mode (P45) and continuous AF function
(P106) cannot be used. Only manual focus is
possible when using a lens that is not
compatible with the Contrast AF. There are
some restrictions to some other functions too.
Because of its structure, Micro Four Thirds mount specification lenses cannot be used on
the Four Thirds mount specification cameras. It can only be used on the Micro Four Thirds
mount specification cameras.
Lens Installation Combination Diagram
1 Micro Four Thirds mount
specification lens
¢
2 Four Thirds mount
specification lens
3 Mount adaptor (DMW-MA1)
4 Micro Four Thirds mount
specification camera
(DMC-G1)
5 Four Thirds mount
specification camera
¢
It cannot be mounted on the Four
Thirds mount specification camera.
Refer to catalogs/Web pages for most current information regarding compatible lenses.
http://panasonic.co.jp/pavc/global/cs (This Site is English only.)

Panasonic Lumix DMC-G1 Specifications

General

Megapixel	13.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Supported aspect ratios	4:3
Maximum image resolution	4000 x 3000 pixels
Filter size	52 mm
Digital zoom	- x
Focal length range	14 - 45 mm
Number of diaphragm blades	7
Lens structure (elements/groups)	12/9
Interface	USB 2.0, Mini HDMI Type C (1.3b)
Digital SLR	No
Camera shutter speed	1/4000 - 60 s
Effective sensor resolution	12100000 pixels
Focal length (35mm film equivalent)	28 - 90 mm
Auto focusing (AF) modes	multi point auto focus, single auto focus
Closest focusing distance	0.30 m
Compatible memory cards	mmc, sd
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	1.4x / 0.7x x
Viewfinder type	Optical
USB version	2.0
Scene modes	Children, Night portrait, party (indoor), Portrait, Sports, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
White balance	auto, Cloudy, daylight, flash, Shade
Camera playback	single image, slide show
Self-timer delay	2 s
Product color	Black
Battery capacity	1250 mAh
Battery life (CIPA standard)	330 shots
Bundled software	PHOTOfunSTUDIO -viewer- 2.1 E / SILKYPIX Developer Studio 3.0 SE / USB Driver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Light metering	Centre-weighted, Spot
Light exposure modes	aperture priority AE, auto, manual, shutter priority AE

Weight and Dimensions

Depth	45.2 mm
Width	124 mm
Height	83.6 mm
Weight	385 g
