2. Getting Started/Basic Operations
40
The shutter button works in two steps. To take a picture, press it.
Press the shutter button halfway to focus.
A Aperture value
B Shutter speed
C Focus indication
• Aperture value and shutter speed are displayed.
(It will flash in red if the correct exposure is not achieved,
except when set to flash.)
• Once the subject is in focus, the focus indication is displayed.
(When the subject is not in focus, the indication flashes)
Press the shutter button fully (push it in further),
and take the picture.
• When the image is correctly focused, the picture will be taken, since the [Focus/Release
Priority] (P152) is set initially to [FOCUS].
• The focus range is different depending on the lens used.
• Even during menu operation or image playback, if you press the shutter button halfway, you
can instantly set the camera ready for recording.
Shutter button (Taking pictures)
When the interchangeable lens
(H-FS12032) is used
0.2 m (0.66 feet) to ¶ (from the focus distance
reference line)
(focal length 12 mm to 20 mm)
0.3 m (0.98 feet) to ¶ (from the focus distance
reference line)
(focal length 21 mm to 32 mm)
When the interchangeable lens
(H-FS35100) is used
0.9 m (3.0 feet) to ¶ (from the focus distance
reference line)
When the interchangeable lens
(H-X015) is used
0.2 m (0.66 feet) to ¶ (from the focus distance
reference line)
To Next Page
